Dahua NVR41 series User Manual

User's Manual
15
Icon
Name
Function
Reverse/Pause
In normal playback or pause mode, click this
button to reverse playback.
In reverse playback, click this button to pause
playback.
Play Next
In playback mode, playback the next video.
In menu setup, go to down ward of the
drop-down list.
Play/Pause
In normal playback click this button to pause
playback.
In pause mode, click this button to resume
playback.
Window switch
Mult
Click it to switch one-window/multiple-window.
Shuttle(outer
ring)
In real-time monitor mode it works as left/right
direction key.
Playback mode, counter clockwise to forward
and clock wise to backward.
Jog(inner dial)
Up/down direction key.
Playback mode, turn the inner dial to realized
frame by frame playback. (Only applies to some
special versions.)
USB port
To connect USB storage device, USB mouse.
Remote control
indicator light
ACT
Remote control indicator light.
Status indicator
light
Status
If there is Fn indicator light, current status
indicator light is null.
Power indicator
light
PWR
Power indicator light.
Channel
indicator
light
1-32
For 4/8/16-channel series product.
The corresponding channel light becomes on
when system is recording.
For 32/64-channel series product:
● When the light flashes slowly, it means the
corresponding channel of 1-16 channel is
recording now (Such as channel 1).
● When the light flashes fast, it means the
corresponding channel of 17-32 channel is
recording now (Such as channel 17).
● When the light becomes on, It means the
corresponding 2 channels are recoding now
(Such as channel 1 and channel 17.).
The channel indicator light here does not show
the status of the 33-64-channel.
IR Receiver
IR
It is to receive the signal from the remote control.
