Dahua NVR41 series

User's Manual
27
Figure 2-31 Rear panel
Table 2-18
Icon
Name
Function
Power input socket.
Power socket. Input DC12V/2A.
Network port
10M/100Mbps self-adaptive Ethernet port.
Connect to the network cable.
USB2.0 port
USB2.0 port. Connect to mouse, USB storage
device, and etc.
HDMI
High Definition
Media Interface
High definition audio and video signal output
port. It transmits uncompressed high definition
video and multiple-channel data to the HDMI
port of the display device. HDMI version is 1.4.
VGA
VGA video output
port
VGA video output port. Output analog video
signal. It can connect to the monitor to view
analog video.
GND
Ground end
Wireless AP
-
Support wireless hotspot function. Use Wi-Fi to
connect to the network camera when there is a
hotspot.
