Dahua NVR41 series User Manual

User's Manual
37
Figure 2-50
The NVR54-16P-4KS2E series rear panel is shown as below. See Figure 2-48.
Figure 2-51
The NVR58-16P-4KS2E series rear panel is shown as below. See Figure 2-48.
Figure 2-52
Table 2-23
Name
Function
Power switch
Power on-off button
Power input port
Input AC 100~240V.
Network port
10M/100M/1000Mbps self-adaptive Ethernet
port. Connect to the network cable.
eSATA
eSATA port
External SATA port. It can connect to the
device of the SATA port. Please jump the
HDD when there is peripheral connected
HDD.
USB3.0 port
USB3.0 port. Connect to mouse, USB storage
device, USB burner and etc.
HDMI
High Definition Media
Interface
High definition audio and video signal output
port. It transmits uncompressed high definition
video and multiple-channel data to the HDMI
port of the display device. HDMI version is
1.4b.
