User's Manual
52
Figure 2-71
Table 2-30
USB2.0 port. Connect to mouse, USB
storage device, USB burner and etc.
10M/100Mbps self-adaptive Ethernet port.
Connect to the network cable.
High Definition Media
Interface
High definition audio and video signal
output port. It transmits uncompressed
high definition video and multiple-channel
data to the HDMI port of the display
device. HDMI version is 1.4.
VGA video output port. Output analog
video signal. It can connect to the monitor
to view analog video.
Device Wi-Fi reset and WPS function
button:
● Hold down this button for 5 seconds
and above to restore Wi-Fi AP to
defaults.
● Press this button for less than 2
seconds, and then press the WPS
button of Wi-Fi IPC, the device and
Wi-Fi IPC can be connected.
