User's Manual

Figure 3-28 Unlock front panel

Step 2 Press the button on the 2 sides to open the front panel.

Figure 3-29 Open front panel

Step 3 Match the 4 screw holes on the HDD with the 4 holes on the bracket and then fasten the

screws.

Figure 3-30 Fasten HDD

Step 4 Push the HDD box into the device.
