User's Manual
305
Figure 5-195 Configure entries frequency
Table 5-54 Entries frequency parameters
Parameter Description
Statistical Cycle Set the cycle for counting the entries frequency.
Entries Detected
Set the threshold of entries frequency. When the entries detected
reaches or exceeds the threshold, an alarm is triggered.
Alarm Name
The name is
Entries Frequency
by default. You can change the name.
Step 4 Click
Apply
.
5.9.19 Smart Object Detection
You can configure rules and set parameters. When someone is taking or placing an item in the
monitoring area, an alarm is triggered.
5.9.19.1 Configuring Smart Plan
To use the smart detection function, you need to enable the smart plan first. For details, see "5.9.3
Smart Plan".
5.9.19.2 Configuring Object Detection
Procedure
Step 1 Select
AI
>
Parameters
>
Smart Object Detection
.
Step 2 Select channel and type, and then click
Apply
.
