30
Figure 5-18
Figure 5-19
Set according to actual network access mode. Step 4
Wired IP
Enter “Local IP”, “Subnet Mask” and “Gateway”, press [OK]. Or press to enable
DHCP function and obtain IP info automatically.
If the device has wireless function, please click “Wired IP” tab to set it.
WLAN
Press to enable WIFI function. 1.
The system displays available WIFI list, as shown in Figure 5-20.
