Daikin DZ20VC Service Manual

Name: Daikin DZ20VC
Brand: Daikin
Rating: 4 (1 reviews)

112 pages

To Next Page

To Previous Page

ACCESSORIES

SS = 2°C (3.6°F) or according

to customer speci cation

Number of turns

from SS to

tight spring

Number of turns

from SS to

loose spring

R22 +7.25 –4.25

R410A +9.5 –2

R410A: 0.6°C / turn - 1.1°F /

R410A - Max. 75°C (167°F)

Number of turns Number of turns

from SS to from SS to

TIGHT Spring LOOSE Spring

R410A +9.5 -2





EXPANSION VALVES

Model Name TXV-Kit

DZ20VC0241** TXV-V24

DZ20VC0361** TXV-V36

DZ20VC0481** TXV-V48

DZ20VC0601** TXV-V60

DZ20VC***1**

Questions and Answers:

Need help?

Do you have a question about the Daikin DZ20VC and is the answer not in the manual?

General

Type	Inverter
Refrigerant	R-410A
Stages	Variable Speed
HSPF Rating	Up to 10
Power Supply	208/230V, 1-Phase, 60Hz
Heating Capacity	24, 000 - 60, 000 BTU/h
Warranty	12-Year Parts Limited Warranty
Indoor Unit Noise Level	37 dB
Outdoor Unit Noise Level	54 dB
Indoor Unit Dimensions (WxHxD)	Varies by model
Indoor Unit Weight	Varies by model
Energy Efficiency Ratio (EER)	13 EER
