TESTING CAPACITOR RESISTANCE
DZ20VC0241**
A VOID CONTACT WITH THE CHARGED AREA .
•N
EVER TOUCH THE CHARGED AREA BEFORE CONFIRMING THAT THE RESIDUAL VOLTAGE IS 50 VOLTS OR LESS .
1. S
HUT DOWN THE POWER AND LEAVE THE CONTROL BOX FOR 10 MINUTES .
2. M
AKE SURE TO TOUCH THE E ARTH GROUND TERMINAL TO RELEASE THE STATIC ELECTRICITY FROM YOUR BODY ( TO PREVENT
FAILURE OF THE PC BOARD ).
3. M
EASURE THE RESIDUAL VOLTAGE IN THE SPECIFIED MEASUREMENT POSITION USING A VOM WHILE PAYING ATTENTION NOT TO
TOUCH THE CHARGED AREA .
4. I
MMEDIATELY AFTER MEASURING THE RESIDUAL VOLTAGE , DISCONNECT THE CONNECTORS OF THE OUTDOOR UNIT ’ S FAN
MOTOR . (I F THE FAN BLADE ROTATES BY STRONG WIND BLOWING AGAINST IT , THE CAPACITOR WILL BE CHARGED, CAUSING
THE DANGER OF ELECTRICAL SHOCK .)
WARNING
Capacitor Voltage
