Daikin DZ20VC - Valid Switch Settings; Condensate Management Kits

6
MODELS
HKSX03XC HKSX05XC HKSX06XC HKSX08XC HKSX10XC HKSC05XC HKSC08XC HKSC10XC
HKSC15XA
HKSC15XB
HKSC15XF
HKSC19CA HKSC19CB
HKSC20DH HKSC20DB
HKSC20XF
HKSC25DA HKSC25DB
DV25PECB14A*
XXXXXXXX
DV37PECC14A*
XXXXXXXXXXXX
DV59PECD14A*
XXXXXXX XX XX
DV61PECD14A*
XXXXXXX XX XXXXX
*Revision level that may or may not be designated.
NOTE: Airflow selection should meet the minimum requirements as mentioned in the air handler installation instructions.
ACCESSORIES
NOTE: For emergency mode heating, set the dipswitch on Control Board. For heating mode, use the thermostat user
menu.
For heater kit installation, it is important to set the capacity of the electric heater at Set-up menu on thermostat and DIP switch on
indoor unit control board. For more information, please see indoor unit I/O manual.
Heater Kit
Selection DV25PECB14A* DV37PECC14A*+ DV59PECD14A*++ DV61PECD14A* S-9 S-10 S-11 S-12
No heater----OFFOFFOFFOFF
First 3 5 5 5 ON ON ON ON
Second5666ONONONOFF
Third 6 8 8 8 ON ON OFF ON
Fourth 8 10 10 10 ON ON OFF OFF
Fifth10151515ONOFFONON
Sixth X 19 20 20 ON OFF ON OFF
Seventh X X X 25 ON OFF OFF ON
VALID SWITCH SETTINGS
Heater kW Dip Switch Setting IndoorControl Board DS Bank 3
+
For match up with a 2 ton outdoor unit: Heater kit application shall not exceed 10 kW.
++
For match up with a 3 ton outdoor unit: Heater kit application shall not exceed 15 kW.
HEATER K IT
Condensate Management Kits*
CMK0008 CMK0009 CMK0010 CMK0011
DV25PECB14** DV37PECC14** DV59PECD14** DV61PECD14**
DFK-B DFK-C DFK-D
DV25PECB14** DV37PECC14** DV59PECD14**
DV61PECD14**
DV**PEC
