7-SEGMENT DISPLAY-OUTDOOR UNIT
SCREEN 3 (SETTING MODE 1 )
7-6ඍඏඕඍඖග'එඛ඘ඔඉඡ
SCREEN 3 (SETTING MODE 1)
Setting No. Contents Setting Installer/Serviceman Notes
1 Cool Airflow Trim High
*1, *2
0: -15% 2: -5% 4: 5% 6: 15%
1: -10% 3: 0% 5: 10%
2 Cool Airflow Trim Int 0: -15% 3: 0% 6: 15%
9: Full
*3
1: -10% 4: 5% 7: 20%
2: -5% 5: 10% 8: 30%
3 Cool Airflow Trim Low 0: -15%
3: 0% 6: 15%
9: Full
*3
1: -10% 4: 5% 7: 20%
2: -5% 5: 10% 8: 30%
4 Cool Profile 0: A 1: B 2: C
3: D
5 Cool Fan ON Delay
0: 5sec. 1: 10sec. 2: 20sec. 3: 30sec.
6 Cool Fan OFF Delay
0: 30sec. 1: 60sec. 2: 90sec. 3: 120sec.
7 Dehumidification Select
*4
0: STD 2: A 4: C
1: OFF 3: B
8 Heat Airflow Trim High
*1
0: -15% 2: -5% 4: 5% 6: 15%
1: -10% 3: 0% 5: 10%
9 Heat Airflow Trim Int 0: -15% 2: -5% 4: 5% 6: 15%
1:
-10%
3: 0%
5: 10%
10 Heat Airflow Trim Low 0: -15% 2: -5% 4: 5% 6: 15%
1: -10%
3: 0% 5: 10%
11 Heat Fan ON Delay
0: 5sec. 1: 10sec. 2: 15sec.
12 Heat Fan OFF Delay
0: 30sec. 1: 50sec. 2: 70sec. 3: 90sec.
13
Airflow Trim Offset
*1, *2
0: 0% 1: +2.5% Used for additional trim setting by adding
2.5% to basic airflow trim setting. This
setting affects all trim settings except
+15% High (cooling or heating).
NOTE:・WĂƌĂŵĞƚĞƌƐĂƐƉĞƌĨĂĐƚŽƌLJƐĞƫŶŐĂƌĞŚŝŐŚůŝŐŚƚĞĚŝŶďŽůĚĂŶĚƵŶĚĞƌůŝŶĞĚ
1 DZ20VC0 more
ŵĂƚĐŚŝŶŐ error
2 DepeŶĚŝŶŐŽŶƚŚe ĐŽŶŶecteĚŝŶĚŽŽrƵŶŝƚ, ƚŚĞre are restrŝĐƟŽŶƐŽŶƚŚeƉŽƐŝƟvĞƐŝĚe TrŝŵƐeƫŶŐ
If yoƵ
ƐŝĚe,ďĞƐƵre ƚŽĐŽŶĮrŵƚŚe ŽŶƐ ŝŶƚŚe ůĂƚĞƐƚŝŶĚŽŽrƵŶŝƚŝŶƐƚĂůůĂƟŽŶ ŵĂŶƵĂů
dŚeůĂƚĞƐt
3
4 Půease S forĚĞƚĂŝůs ŽĨƚŚŝs ĨƵŶĐƟŽŶ
TrŝŵƐĞƫŶŐŝŶƐƚeĂĚŽf
・dŚĞƐƉĞĐŝĮĐĂƟŽŶŽĨϮϬsϬϮϰϭϬϯϲϭϬϰϴϭĂŶĚϬϲϬϭŽƌĞĂƌůŝĞƌŵŽĚĞůƐĂƌĞĚŝīĞƌĞŶƚĨƌŽŵƚŚŝƐƐƉĞĐŝĮĐĂƟŽŶ
&ŽƌĚĞƚĂŝůƐƐĞĞƚŚĞ/ŶƐƚĂůůĂƟŽŶDĂŶƵĂůŽƌ^ĞƌǀŝĐĞDĂŶƵĂůƚŚĂƚŵĂƚĐŚĞƐƚŚĞDĂũŽƌĂŶĚDŝŶŽƌƌĞǀŝƐŝŽŶŽĨŵŽĚĞůŶĂŵĞ
