Daikin Floor Standing Type F-Series - Page 160

Indoor Unit SiBE06-708_A
149 Removal Procedure
5 Remove the 2 screws
to remove the swing
motor.
2. Remove the vertical blade
(lower).

Be careful not to wet the
floor with drain.
1
Remove the 2 screws.
2 Remove the drain hose
and release the
harness of the lower air
outlet motor from the
hook.
Step Procedure Points
Swing motor
(R6807)
Shaft
(R6808)
Hook
Drain hose
(R6810)
