Indoor Unit SiBE041102_A
106 Removal Procedure
4
Unfasten the 3 hooks at
the shaft mounting part
by pressing them with a
flat screwdriver.
5
Remove the vertical
blade ASSY.
Repeat the same procedure
to remove the vertical blade
ASSY on the other side.
Step Procedure Points
(R8022)
Hook
(R8023)
