Table 5 continued: Group 01: Operating Data
0131 PID 2 FBK
Unit and
scale
dened by
par. 4206
and 4207
— —
The PID 2 controller feedback signal.
• Units and scale dened by PID parameters.
0132 PID 1 DEVIATION
Unit and
scale
dened
by par.
4006/4106
and
4007/4107
— —
The difference between the PID 1 controller reference value and actual value.
• Units and scale dened by PID parameters.
0133 PID 2 DEVIATION
Unit and
scale
dened by
par. 4206
and 4207
— —
The difference between the PID 2 controller reference value and actual value.
• Units and scale dened by PID parameters.
0134 COMM RO WORD 0…65535 1 —
Free data location that can be written from serial link.
• Used for relay output control.
0135 COMM VALUE 1
-32768…
+32767
1 —
Free data location that can be written from serial link.
0136 COMM VALUE 2
-32768…
+32767
1 —
Free data location that can be written from serial link.
0137 PROCESS VAR 1 — 1 —
Process variable 1
• Dened by parameters in Group 34: Panel Display on page 34.
0138 PROCESS VAR 2 — 1 —
Process variable 2
• Dened by parameters in Group 34: Panel Display on page 34.
0139 PROCESS VAR 3 — 1 —
Process variable 3
• Dened by parameters in Group 34: Panel Display on page 34.
0140 RUN TIME
0.00…499.99
kh
0.01 kh —
The drive’s accumulated running time in thousands of hours (kh).
• Cannot be reset.
0141 MWH COUNTER
0…65535
MWh
1 MWh —
The drive’s accumulated power consumption in megawatt hours.
• The counter value is accumulated till it reaches 65535 after which the counter rolls over and starts again from 0.
• Cannot be reset.
0142 REVOLUTION CNTR
0…65535
Mrev
1 Mrev —
The motor’s accumulated revolutions in millions of revolutions.
• Can be reset by pressing UP and DOWN keys simultaneously when the control panel is in the Parameters mode.
0143 DRIVE ON TIME HI
0…65535
days
1 day —
The drive’s accumulated power-on time in days.
• Cannot be reset.
0144 DRIVE ON TIME LO
00:00:00…
23:59:58
1 = 2 s —
The drive’s accumulated power-on time in 2 second ticks (30 ticks = 60 seconds).
• Shown in format hh.mm.ss.
• Cannot be reset.
ParaMeTers
