Pin
Pin name
Function
Comment
1
Centre
Frame Clock in
32kHz, 44.1kHz, 48kHz, +/- 100ppm, +5V TTL,
switchable 75Ohm terminator.
GND
GND
Ground Frame Clock in
Table 9-1: Frame clock input BNC
Pin
Pin name
Function
Comment
1
Centre
Frame Clock Out
32kHz, 44.1kHz, 48kHz, +5V TTL, imp.: 75Ohm
GND GND
Ground Frame Clock
out
Table 9-2: Frame clock output BNC
Pin
Pin name
Function
Comment
1
Red
Red Video Out
Red Video
2
Green
Green Video Out
Green Video
3
Blue
Blue Video Out
Blue Video
4
nc
5
GND Hsync
GND Horizontal Sync
6
Red_RTN
Red Video Return
Red Video
7
Green_RTN
Green Video Return
Green Video
8
Blue_RTN
Blue Video Return
Blue Video
9
+5V
Power DDC
DCC
10
GND
GND (Vsync, DCC)
Ground
11
nc
12
DDDA
Data DDC
DCC
13
Hsync
Horizontal Sync
Horizontal Sync
14
Vsync
Vertical Sync
Vertical Sync
15
DDCK
CLK DDC
DCC
S
Shield
Ground
Table 9-3: VGA 15p D-Sub connector
Pin
Pin name
Function
Comment
1
KB Data
Keyboard/Mouse Data
Keyboard/Mouse Connection
5
KB CLK
Keyboard/Mouse CLK
2
not connected
6
4
PWR
+5V Power
Power Connection
3
GND
Ground
S
Shield
Ground
Ground
Table 9-4: Keyboard & Mouse mini DIN connector
Pin
Pin name
Function
Comment
1a/b
VBUS
+5V Power
Supply power
2a/b
nUSB
USB Data outface
USB
3a/b
USB
USB Data inface
4a/b
GND
Ground
Ground
S
Shield
Ground
Ground
Table 9-5: USB connector (2x)
