Pin
Pin name
Function
1
DCD
Carrier Detect
6
DSR
Data Set Ready
2
RD
Receive Data
7
RTS
Request To Send
3
TD
Transmit Data
8
CTS
Clear To Send
4
DTR
Data Terminal Ready
9
RI
Ring Indicator
5
GND
Ground
S
Shield
Ground
Table 9-6: RS232 9pin SUB-D connector
Pin
Con.
Pair
Pin name
Function
Comment
1
1A
1
TX +
Ethernet
Ethernet TX 10/100BASE-T
2
1B
TX -
Ethernet
3
2A
2
RX+
Ethernet
Ethernet RX 10/100BASE-T
6
2B
RX-
Ethernet
5
3A
3
NC
4
3B
NC
7
4A
4
NC
8
4B
NC
S
GND
S
Shield
GND
Ground
Table 9-7: Ethernet RJ45 connection
