Communication
The Comm (Communications) screen allows for IP network
settings to be congured. Follow the question lines on the screen
to congure your AK-SM according to site requirements. Any
changes in IP conguration will require an AK-SM system reset.
Internet IP address - Specify public IP address which is
used to contact your AK-SM via an Internet based
connection. Factory web (HTTP) port is 80 & FTP port is
20 and 21, both can be changed to suit your network
application.
If your network supports NTP, select ‘yes’ to the
question ‘Network timing support?’
Select ‘Yes’ if a DNS service is to be used. Prefered host
name can be entered if setup in router cong
Select ‘Yes’ if AK-SM is to be connected to a DHCP server
Select yes and manually enter the IP address that the
AK-SM will use if DHCP fails.
5
Alarms
The Alarms screen has a sub set of screen [Connections, Service, Alarm Routing, Relays, System, I/O Comm]. Go through each sub tab to
ensure all areas are correctly congured as per site requirements.
Master IP address - if using multiple AK-SM controllers in
a host network, enter the Master (unit address 0) IP
address
Dene the number of
connections (typically
network should be selected),
then select the connection
type [e-mail, Remote (Danfoss
Retail Care), XML)
The service tab is designed to
allow test alarms to be
generated. There is also an
auto alarm test that can either
be on a scheduled or repeated
basis.
The AK-SM utilizes an
Alarm Action Matrix that
allows a high degree of
exibility for various
alarm routing options.
At the heart of the alarm
conguration is the
‘Alarm Routing’ page,
where dierent routing
options can be dened,
along with time delays
and alarm output stop
conditions.
If the alarm output
includes relay(s) the
Relays tab should be
accessed to congure
the board & point
address for these relays
AK-SM system
based alarm
conditions
should be set
under the
System tab.
If Controllers (Danfoss Evap &
Pack, Power meters) and, I/O
has been used in the control
conguration (Lighting, HVAC,
Refrigeration etc.), these
devices can be seen under the
I/O Comm tab.
