Danfoss FC 102 User Manual

N500 N560
Normal overload NO NO
(Normal overload=110% current during 60 s)
Typical shaft output at 400 V [kW] 500 560
Typical shaft output at 460 V [hp] 650 750
Typical shaft output at 480 V [kW] 560 630
Enclosure size E2h/E4h E2h/E4h
Output current (3-phase)
Continuous (at 400 V) [A] 880 990
Intermittent (60 s overload)
(at 400 V) [A]
968 1089
Continuous (at 460/480 V) [A] 780 890
Intermittent (60 s overload)
(at 460/480 V) [A]
858 979
Continuous kVA (at 400 V) [kVA] 610 686
Continuous kVA (at 460 V) [kVA] 621 709
Continuous kVA (at 480 V) [kVA] 675 771
Maximum input current
Continuous (at 400 V) [A] 848 954
Continuous (at 460/480 V) [A] 752 848
Maximum number and size of cables per phase (E2h)
- Mains and motor without brake [mm
2
(AWG)]
1)
6x240 (6x500 mcm) 6x240 (6x500 mcm)
- Mains and motor with brake [mm
2
(AWG)]
1)
5x240 (5x500 mcm) 5x240 (5x500 mcm)
- Brake or regeneration [mm
2
(AWG)]
1)
2x185 (2x350 mcm) 2x185 (2x350 mcm)
Maximum number and size of cables per phase (E4h)
- Mains and motor [mm
2
(AWG)]
1)
6x240 (6x500 mcm) 6x240 (6x500 mcm)
- Brake [mm
2
(AWG)]
1)
2x185 (2x350 mcm) 2x185 (2x350 mcm)
- Load share or regeneration [mm
2
(AWG)]
1)
4x185 (4x350 mcm) 4x185 (4x350 mcm)
Maximum external mains fuses [A]
2)
1200 1200
Estimated power loss at 400 V [W]
3) 4)
9473 11102
Estimated power loss at 460 V [W]
3)4)
7809 9236
Eciency
4)
0.98 0.98
Output frequency 0–590 Hz 0–590 Hz
Heat sink overtemperature trip [°C (°F)]
110 (230) 100 (212)
Control card overtemperature trip [°C (°F)]
80 (176) 80 (176)
Power card overtemperature trip [°C (°F)]
85 (185) 85 (185)
Fan power card overtemperature trip [°C (°F)]
85 (185) 85 (185)
Active in-rush card overtemperature trip [°C (°F)]
85 (185) 85 (185)
Table 9.2 Technical Specications, Mains Supply 3x380–480 V AC
1) American Wire Gauge.
2) For fuse ratings, see chapter 9.7 Fuses.
3) Typical power loss is at normal conditions and expected to be within ± 15% (tolerance relates to variety in voltage and cable conditions.) These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies for
dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control
card power consumptions are included. For power loss data according to EN 50598-2, refer to www.danfoss.com/vltenergyeciency. Options and
customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each add only 4 W.
4) Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy
eciency class, see chapter 9.4 Ambient Conditions. For part load losses, see www.danfoss.com/vltenergyeciency.
