9.1.2 Mains Supply 3x525–690 V AC
N450 N500 N560 N630
Normal load NO NO NO NO
(Normal overload=110% current during 60 s)
Typical shaft output at 550 V [kW] 355 400 450 500
Typical shaft output at 575 V [hp] 450 500 600 650
Typical shaft output at 690 V [kW] 450 500 560 630
Enclosure size E1h/E3h E1h/E3h E1h/E3h E1h/E3h
Output current (3-phase)
Continuous (at 550 V) [A] 470 523 596 630
Intermittent (60 s overload) (at 550 V) [A] 517 575 656 693
Continuous (at 575/690 V) [A] 450 500 570 630
Intermittent (60 s overload) (at 575/690 V) [A] 495 550 627 693
Continuous kVA (at 550 V) [kVA] 448 498 568 600
Continuous kVA (at 575 V) [kVA] 448 498 568 627
Continuous kVA (at 690 V) [kVA] 538 598 681 753
Maximum input current
Continuous (at 550 V) [A] 453 504 574 607
Continuous (at 575 V) [A] 434 482 549 607
Continuous (at 690 V) [A] 434 482 549 607
Maximum number and size of cables per phase (E1h)
- Mains and motor without brake [mm
2
(AWG)]
1)
5x240 (5x500
mcm)
5x240 (5x500
mcm)
5x240 (5x500
mcm)
6x240 (6x500
mcm)
- Mains and motor with brake [mm
2
(AWG)]
1)
4x240 (4x500
mcm)
4x240 (4x500
mcm)
4x240 (4x500
mcm)
5x240 (5x500
mcm)
- Brake or regeneration [mm
2
(AWG)]
1)
2x185 (2x350
mcm)
2x185 (2x350
mcm)
2x185 (2x350
mcm)
2x185 (2x350
mcm)
Maximum number and size of cables per phase (E3h)
- Mains and motor [mm
2
(AWG)]
1)
6x240 (6x500
mcm)
6x240 (6x500
mcm)
6x240 (6x500
mcm)
6x240 (6x500
mcm)
- Brake [mm
2
(AWG)]
1)
2x185 (2x350
mcm)
2x185 (2x350
mcm)
2x185 (2x350
mcm)
2x185 (2x350
mcm)
- Load share or regeneration [mm
2
(AWG)]
1)
4x185 (4x350
mcm)
4x185 (4x350
mcm)
4x185 (4x350
mcm)
4x185 (4x350
mcm)
Maximum external mains fuses [A]
2)
800 800 800 800
Estimated power loss at 600 V [W]
3)4)
6062 6879 8076 9208
Estimated power loss at 690 V [W]
3)4)
5939 6715 7852 8921
Eciency
4)
0.98 0.98 0.98 0.98
Output frequency [Hz] 0–590 0–590 0–590 0–590
Heat sink overtemperature trip [°C (°F)]
110 (230) 110 (230) 110 (230) 110 (230)
Control card overtemperature trip [°C (°F)]
80 (176) 80 (176) 80 (176) 80 (176)
Power card overtemperature trip [°C (°F)]
85 (185) 85 (185) 85 (185) 85 (185)
Fan power card overtemperature trip [°C (°F)]
85 (185) 85 (185) 85 (185) 85 (185)
Active in-rush card overtemperature trip [°C (°F)]
85 (185) 85 (185) 85 (185) 85 (185)
Table 9.3 Technical Specications, Mains Supply 3x525–690 V AC
Specications VLT® HVAC Drive FC 102
76 Danfoss A/S © 01/2017 All rights reserved. MG16O102
