Danfoss FC 300

FC 300 Operating Instructions
How to Programme
" 15-** Drive Information
Par.
No.
#
Parameter description Default value
(SR = Size
Related)
4-set-up Change
during
operation
Conver-
sion index
Type
15-0* Operating Data
15-00 Operating Hours 0 h All set-ups FALSE 74 Uint32
15-01 Running Hours 0 h All set-ups FALSE 74 Uint32
15-02 kW h Counter 0 kWh All set-ups FALSE 75 Uint32
15-03 Power Up’s 0 All set-ups FAL SE 0 Uint32
15-04 Over Temp’s 0 All s et-ups FAL SE 0 Uint16
15-05 Over Volt’s 0 A ll set-ups FALSE 0 Uint16
15-06 Reset kWh Counter [0] Do not reset All set-ups TRUE - Uint8
15-07 Reset Running Hours Counter [0] Do not reset All set-ups TRUE - Uint8
15-1* D at a Log Settings
15-10 Logging Source 0 2 set-ups TRUE - Uint16
15-11 Logging Interval SR 2 set-ups TRUE -3 TimD
15-12 Trigger Event [0] False 1 set-up TRUE - Uint8
15-13 Logging Mode [0] Log always 2 set-ups TRUE - Uint8
15-14 Sam ples Before Trigger 50 2 set-ups TRUE 0 Uint8
15-2* Historic Log
15-20 Historic Log: Event 0 All set-ups FALSE 0 Uint8
15-21 Historic Log: Value 0 All set-ups FALSE 0 Uint32
15-22 Historic Log: Time 0 ms All set-ups FALSE -3 Uint32
15-3* Fault Log
15-30 Fault Log: Error Code 0 All set-ups FALSE 0 Uint8
15-31 Fault Log: Value 0 All set-ups FALSE 0 Int16
15-32 Fault Log: Time 0 s All set-ups FAL SE 0 Uint32
15-4* Drive Identification
15-40 FC Type 0 All s et-ups FALSE 0 VisStr[6]
15-41 Power Section 0 All set-ups FALSE 0 VisStr[20]
15-42 Voltage 0 All set-ups FALSE 0 VisStr[20]
15-43 Software Version 0 All set-ups FALSE 0 VisStr[5]
15-44 Ordered Typecode String 0 All set-ups FALSE 0 VisStr[40]
15-45 Actua l Typecode String 0 All set-ups FALSE 0 VisStr[40]
15-46 Frequency Converter Ordering No 0 All set-ups FALSE 0 VisStr[8]
15-47 Power Card Ordering No 0 All set-ups FAL SE 0 VisStr[8]
15-48 LCP Id No 0 All set-ups FALSE 0 VisStr[20]
15-49 SW ID Control Card 0 All set-ups FALSE 0 VisStr[20]
15-50 SW ID Power Card 0 All set-ups FALSE 0 VisStr[20]
15-51 Frequency Converter Serial Number 0 All set-ups FAL S E 0 VisStr[10]
15-53 Power Card Serial Numb er 0 All set-ups FALSE 0 VisStr[19]
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
