Danfoss FC 300

FC 300 Operating Instructions
How to Programme
" 14-** Special Functions
Par.
No.
#
Parameter description Default value
(SR = Size Related)
4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
14-0* Inverter Switching
14-00Switching Pattern [1] SFAVM All set-ups TRUE - Uint8
14-01Switching Frequency - All set-ups TRUE - Uint8
14-03Overmodulatio n [1] O n A l l set- up s FALSE - Uint8
14-04PWM Random [0] Off All set-ups TRUE - Uint8
14-1* M a in s On/Off
14-10Mains Failure [0] No function All set-ups FALSE - Uint8
14-11Mains Voltage at M ains Fault SR All set-ups TRUE 0 Uint16
14-12Function at Mains Imbalance [0] Trip All set-ups TRUE - Uint8
14-2* Trip Reset
14-20Reset Mode [0] Manual reset All set-ups TRUE - Uint8
14-21Automatic Restart Time 10 s All set-ups TRUE 0 Uint16
14-22Operation Mode [0] Normal operation All set-ups TRUE - Uint8
14-23Typecode Setting - 2 set-ups FALSE - Uint16
14-25Trip Delay at Torque Limit 60 s All set-ups TRUE 0 Uint8
14-26Trip Delay at Inverter Fault SR All set-ups TRUE 0 Uint8
14-28Production Settings [0] No act ion All set-ups TRUE - Uint8
14-29Service Code 0 All set-ups TRUE 0 Int32
14-3* Current Limit Ctrl.
14-30Current Lim Cont, Proportional Gain 100 % All set-ups FALSE 0 Uint16
14-31Current Lim Contr, Integration Time 0.020 s All set-ups FALSE -3 Uint16
14-4* Energy Optimising
14-40VT Level 66 % All set-ups FALSE 0 Uint8
14-41AEO Minimum Magnetisation 40 % All set-ups TRUE 0 Uint8
14-42Minimum AEO Frequency 10 Hz All set-ups TRUE 0 Uint8
14-43Motor Cosphi SR All set-ups TRUE -2 Uint16
14-5* Environment
14-50RFI Filter [1] On 1 set-up x FALSE - Uint8
14-52 Fan Control [0] Auto All set-ups TRU E - Uint8
14-53Fan Mon it or [1] Warning All set-ups TRU E - Uint8
14-55Output Filter [0] No Filt er 1 set-up FALSE - Ui n t8
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
56
MG.33.A7.02 - VLT is a registered Danfoss trademark
