Danfoss FC 300

FC 300 Operating Instructions
How to Programme
" 16-** D ata Readouts
Par.
No.
#
Parameter description Default value
(SR = Size Related)
4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
16-0* General Status
16-00Control Word 0 All set-ups FALSE 0 V2
16-01Reference [Unit] 0.000 All set-ups FALSE -3 Int32
16-02Reference % 0.0 % All set-ups FALSE -1 Int16
16-03Status Word 0 All set-ups FALSE 0 V2
16-05Main Actual Value [%] 0.00 % All set-ups FALSE -2 N2
16-09Custom Readout 0.00 All set-ups FALSE - 2 Int32
16-1* Motor Status
16-10Power [kW] 0.00 kW All set-ups FALSE 1 Int32
16-11Power [hp] 0.00 hp All set-ups FALSE -2 Int32
16-12Motor Voltage 0.0 V All set-ups FALSE -1 Uint16
16-13Frequency 0.0 Hz All set-ups FALSE -1 Uint16
16-14Motor Current 0.00 A All set-ups FALSE -2 Int32
16-15 F requency [%] 0.00 % All set-ups FALSE -2 N2
16-16Torque [Nm] 0.0 Nm All set-ups FALSE -1 Int16
16-17Speed [RPM] 0 RPM All set-ups FALSE 67 Int32
16-18Motor Thermal 0 % All set-ups FALSE 0 Uint8
16-19KTY sensor temperature 0 °C All set-ups FALSE 100 Int16
16-20Motor Angle 0 All set-ups TRUE 0 Uint16
16-22Torque [%] 0 % All set-ups FALSE 0 Int16
16-3* Drive Status
16-30DC Link Voltage 0 V All set-ups FALSE 0 Uint16
16-32Brake Energy /s 0.000 kW All set-ups FALSE 0 Uint32
16-33 Brake Energy /2 min 0 .0 0 0 kW All set-ups FAL S E 0 U int32
16-34Heatsink Temp. 0 °C All set-ups FALSE 100 Uint8
16-35Inverter Thermal 0 % All set-ups FALSE 0 Uint8
16-36Inv.Nom.Current SR Allset-ups FALSE -2 Uint32
16-37Inv.Max.Current SR Allset-ups FALSE -2 Uint32
16-38SL Controller State 0 All set-ups FALSE 0 Uint8
16-39Control Card Tem p. 0 °C All set-ups FALSE 1 00 Uint8
16-40Logging Buffer Full [0] No All set-ups TRUE - Uint8
16-5* Ref. & Feedb.
16-50Extern a l Reference 0.0 All set-ups FALSE -1 Int16
16-51Pulse Reference 0.0 All set-ups FALSE -1 Int16
16-52Feedback [Unit] 0.000 All set-ups FALSE -3 Int32
16-53Digi Pot Reference 0.00 All set-ups FALSE -2 Int16
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
59
MG.33.A7.02 - VLT is a registered Danfoss trademark
