Danfoss FC 300

FC 300 Operating Instructions
How to Programme
Par.
No.
#
Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
16-6* Inputs & O utputs
16-60Digital Input 0 All set-ups FALSE 0 Uint16
16-61Terminal 53 Switch Setting [0] Current All set-ups FALSE - Uint8
16-62Analog Input 53 0.000 All set-ups FALSE -3 Int32
16-63Terminal 54 Switch Setting [0] Current All set-ups FALSE - Uint8
16-64Analog Input 54 0.000 All set-ups FALSE -3 Int32
16-65Analog Output 42 [mA] 0.000 All set-ups FALSE -3 Int16
16-66Digital Output [bin] 0 All set-ups FALSE 0 Int16
16-67Freq. Input #29 [Hz] 0 All set-ups x FALSE 0 Int32
16-68Freq. Input #33 [Hz] 0 All set-ups FALSE 0 Int32
16-69Pulse Output #27 [Hz] 0 All set-ups FALSE 0 Int32
16-70Pulse Output #29 [Hz] 0 All set-ups x FALSE 0 Int32
16-71 Relay Output [bin] 0 All set-ups FALS E 0 Int16
16-72Counter A 0 All set-ups TRUE 0 Int32
16-73Counter B 0 All set-ups TRUE 0 Int32
16-74Prec. Stop Counter 0 All set-ups TRUE 0 Uint32
16-75Analog In X30/11 0.000 All set-ups FALSE -3 Int32
16-76Analog In X30/12 0.000 All set-ups FALSE -3 Int32
16-77Analog Out X30/8 [mA] 0.000 All set-ups FALSE -3 Int16
16-8* Fieldbus & FC Port
16-80Fieldbus CTW 1 0 All set-ups FALSE 0 V2
16-82Fieldbus REF 1 0 All set-ups FALSE 0 N2
16-84Comm. Option STW 0 All set-ups FALSE 0 V2
16-85FC Port CTW 1 0 All set-ups FALSE 0 V2
16-86FC Port REF 1 0 All set-ups FALSE 0 N2
16-9* Diagnosis Readouts
16-90Alarm Word 0 All set-ups FALSE 0 Uint32
16-91Alarm word 2 0 All set-ups FALSE 0 Uint32
16-92Warning Word 0 All set-ups FALSE 0 Uint32
16-93Warning word 2 0 All set-ups FALSE 0 Uint32
16-94Ext. Status Word 0 All set-ups FALSE 0 Uint32
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
60
MG.33.A7.02 - VLT is a registered Danfoss trademark
