Danfoss FC 300 Operating Instruction

FC 300 Operating Instructions
How to Programme
" 17-** Motor Feedb.Option
Par.
No.
#
Parameter description Default value
(SR = Size related)
4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
17-1* Inc. Enc. Interface
17-10Signal Type [1] RS422 (5V TTL) All set-ups FAL SE - Uint8
17-11 Resolution ( PPR) 1024 All set-ups FALSE 0 Uint16
17-2*Abs.Enc.Interface
17-20Protocol Selection [0] None All set-ups FALSE - Uint8
17-21 Resolution (Positions/Rev) SR All set-ups FALSE 0 Uint32
17-24SSI Data Length 13 All set-ups FALSE 0 Uint8
17-25Clock Rate SR All set-ups FALSE 3 Uint16
17-26SSI Data Format [0] Gray code All set-ups FALSE - Uint8
17-34HIPERFACE Baudrate [4] 9600 All set-ups FALSE - Uint8
17-5* Resolver Interface
17-50Poles 2 1 set-up FALSE 0 Uint8
17-51Input Voltage 7.0 V 1 set-up FALSE -1 Uint8
17-52Input Frequency 10.0 kHz 1 set-up FALSE 2 Uint8
17-53Transformation Ratio 0.5 1 set-up FALSE -1 Uint8
17-59Resolver Interface [0] Disabled All set-ups FALSE - Uint8
17-6* Monitoring and App.
17-60Feedback D ire ct ion [0] Clockwise All set-ups FALSE - Uint8
17-61Feedback Signal Monitoring [1] Warning All set-ups TRUE - Uint8
*
defa
ult setting
()dis
play text
[]val
ue for use in communication via serial c ommunication port
61
MG.33.A7.02 - VLT is a registered Danfoss trademark

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
