Danfoss FC 300

16-17 Speed [RPM]
16-18 Motor Thermal
16-19 KTY Sensor
Temperature
16-21 Phase Angle
16-30 DC Link Voltage
16-32 Brake Energy /
s
16-33 Brake Energy /
2 min 16-34 Heatsink
Temp.
16-35 Inverter Ther-
mal
16-38 SL Control
State
16-39 Control Card
Temp.
16-50 External Refer-
ence
16-51 Pulse Refer-
ence
16-52 Feedback
[Unit]
16-53 Digi Pot Refer-
ence
16-60 Digital Input
16-61 Terminal 53
Switch Setting
16-62 Analog Input
53
16-63 Terminal 54
Switch Setting
16-64 Analog Input
54
16-65 Analog Output
42 [mA]
16-66 Digital Output
[bin]
16-67 Freq. Input
#29 [Hz]
16-68 Freq. Input
#33 [Hz]
16-69 Pulse Output
#27 [Hz]
16-70 Pulse Output
#29 [Hz]
16-71 Pulse Output
[bin]
16-84 Comm Option
STW [Binary]
