0-20 Display Line 1.1 Small

Option: Function:

Regarding order, see

parameter 16-60 Digital Input. Bit 0 is at

the extreme right.

[1661] Terminal 53

Switch Setting

Setting of input terminal 53. Current=0;

Voltage=1.

[1662] Analog Input 53 Actual value at input 53 either as a

reference or protection value.

[1663] Terminal 54

Switch Setting

Setting of input terminal 54. Current=0;

Voltage=1.

[1664] Analog Input 54 Actual value at input 54 either as

reference or protection value.

[1665] Analog Output

42 [mA]

Actual value at output 42 in mA. Use

parameter 6-50 Terminal 42 Output to

select the variable to be represented

by output 42.

[1666] Digital Output

[bin]

Binary value of all digital outputs.

[1667] Pulse Input #29

[Hz]

Actual value of the frequency applied

at terminal 29 as a pulse input.

[1668] Pulse Input #33

[Hz]

Actual value of the frequency applied

at terminal 33 as a pulse input.

[1669] Pulse Output

#27 [Hz]

Actual value of pulses applied to

terminal 27 in digital output mode.

[1670] Pulse Output

#29 [Hz]

Actual value of pulses applied to

terminal 29 in digital output mode.

[1671] Relay Output

[bin]

View the setting of all relays.

[1672] Counter A View the present value of counter A.

[1673] Counter B View the present value of counter B.

[1675] Analog In

X30/11

Actual value of the signal on input

X30/11 (general purpose I/O card.

Optional).

[1676] Analog In

X30/12

Actual value of the signal on input

X30/12 (general purpose I/O card.

Optional).

[1677] Analog Out

X30/8 [mA]

Actual value at output X30/8 (general

purpose I/O card. Optional). Use

parameter 6-60 Terminal X30/8 Output

to select the variable to be shown.

[1678] Analog Out

X45/1 [mA]

[1679] Analog Out

X45/3 [mA]

[1680] Fieldbus CTW 1 Control word (CTW) received from the

bus master.

[1682] Fieldbus REF 1 Main reference value sent with control

word via the serial communications

0-20 Display Line 1.1 Small

Option: Function:

network, for example from the BMS,

PLC, or other master controller.

[1684] Comm. Option

STW

Extended eldbus communication

option status word.

[1685] FC Port CTW 1 Control word (CTW) received from the

bus master.

[1686] FC Port REF 1 Status word (STW) sent to the bus

master.

[1690] Alarm Word 1 or more alarms in a hex code (used

for serial communications).

[1691] Alarm Word 2 1 or more alarms in a hex code (used

for serial communications).

[1692] Warning Word 1 or more warnings in a hex code

(used for serial communications).

[1693] Warning Word 2 1 or more warnings in a hex code

(used for serial communications).

[1694] Ext. Status Word 1 or more status conditions in a hex

code (used for serial communications).

[1695] Ext. Status Word

1 or more status conditions in a hex

code (used for serial communications).

[1696] Maintenance

Word

The bits reect the status for the

programmed preventive maintenance

events in parameter group 23-1*

Maintenance

[1830] Analog Input

X42/1
