0-20 Display Line 1.1 Small
Option: Function:
[1839] Temp. Input
X48/10
[1850] Sensorless
Readout [unit]
[1860] Digital Input 2
[2117] Ext. 1 Reference
[Unit]
The value of the reference for
extended closed loop controller 1
[2118] Ext. 1 Feedback
[Unit]
The value of the feedback signal for
extended closed loop controller 1
[2119] Ext. 1 Output
[%]
The value of the output from extended
closed loop controller 1
[2137] Ext. 2 Reference
[Unit]
The value of the reference for
extended closed loop controller 2
[2138] Ext. 2 Feedback
[Unit]
The value of the feedback signal for
extended closed loop controller 2
[2139] Ext. 2 Output
[%]
The value of the output from extended
closed loop controller 2
[2157] Ext. 3 Reference
[Unit]
The value of the reference for
extended closed loop controller 3
[2158] Ext. 3 Feedback
[Unit]
The value of the feedback signal for
extended closed loop controller 3
[2159] Ext. 3 Output
[%]
The value of the output from extended
closed loop controller 3
[2230] No-Flow Power The calculated no-ow power for the
actual operating speed
[2316] Maintenance
Text
[2580] Cascade Status Status for the operation of the cascade
controller
[2581] Pump Status Status for the operation of each
individual pump controlled by the
cascade controller
[3110] Bypass Status
Word
[3111] Bypass Running
Hours
[9913] Idle time
[9914] Paramdb
requests in
queue
[9920] HS Temp. (PC1)
[9921] HS Temp. (PC2)
[9922] HS Temp. (PC3)
[9923] HS Temp. (PC4)
[9924] HS Temp. (PC5)
[9925] HS Temp. (PC6)
[9926] HS Temp. (PC7)
[9927] HS Temp. (PC8)
[9951] PC Debug 0
0-20 Display Line 1.1 Small
Option: Function:
[9952] PC Debug 1
[9953] PC Debug 2
[9954] PC Debug 3
[9955] PC Debug 4
[9956] Fan 1 Feedback
[9957] Fan 2 Feedback
[9958] PC Auxiliary
Temp
[9959] Power Card
Temp.
0-21 Display Line 1.2 Small
Select a variable for display in line 1, middle position.
Option: Function:
[1614] * Motor Current The options are the same as those listed
in parameter 0-20 Display Line 1.1 Small.
0-22 Display Line 1.3 Small
Select a variable for display in line 1, right position.
Option: Function:
[1610] * Power [kW]
The options are the same as those listed in
parameter 0-20 Display Line 1.1 Small.
0-23 Display Line 2 Large
Select a variable for display in line 2.
Option: Function:
[1613] * Frequency
The options are the same as those listed in
parameter 0-20 Display Line 1.1 Small.
0-24 Display Line 3 Large
Select a variable for display in line 3.
0-25 My Personal Menu
Array [20]
Range: Function:
Size
related*
[0 -
9999 ]
Dene up to 20 parameters to appear in the
Q1 Personal Menu, accessible via the [Quick
Menu] key on the LCP. The parameters will
be displayed in the Q1 Personal Menu in the
order they are programmed into this array
parameter. Delete parameters by setting the
value to ‘0000’.
For example, this can be used to provide
quick, simple access to just 1 or up to 20
parameters which require changing on a
regular basis (e.g. for plant maintenance
reasons) or by an OEM to enable simple
commissioning of their equipment.
Parameter Descriptions Programming Guide
MG11CE02 Danfoss A/S © 03/2015 All rights reserved. 31
3 3
