8-36 Maximum Response Delay
Range: Function:
Size
related*
[ 11 - 10001
ms]
Specify the maximum permissible
delay time between transmitting a
request and receiving a response.
Exceeding this delay time causes
control word timeout.
8-37 Maximum Inter-Char Delay
Range: Function:
Size related* [ 0.00 -
35.00 ms]
Specify the maximum permissible
time interval between receipt of 2
bytes. This parameter activates
timeout if transmission is
interrupted.
3.9.4 8-4* Telegram Selection
8-40 Telegram Selection
Option: Function:
Enables use of freely congurable
telegrams or standard telegrams for
the FC Port.
[1] * Standard telegram 1
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom telegram 1
8-42 PCD Write Conguration
Range: Function:
Size
related*
[0 -
9999]
Select the parameters to be assigned to
the PCD's telegrams. The number of
available PCDs depends on the telegram
type. The values in the PCDs are then
written to the selected parameters as
data values.
8-43 PCD Read Conguration
Range: Function:
Size
related*
[0 -
9999]
Select the parameters to be assigned to
the PCDs of the telegrams. The number
of available PCDs depends on the
telegram type. PCDs contain the actual
data values of the selected parameters.
3.9.5 8-5* Digital/Bus
Parameters for conguring the control word digital/bus
merging.
NOTICE
These parameters are active only when
parameter 8-01 Control Site is set to [0] Digital and control
word.
8-50 Coasting Select
Option: Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
[0] Digital
input
Activates start command via a digital input.
[1] Bus Activates start command via the serial
communication port or eldbus option.
[2] Logic AND Activates start command via the eldbus/serial
communication port, AND 1 additional digital
input.
[3] * Logic OR Activates start command via the eldbus/serial
communication port OR via 1 of the digital
inputs.
8-52 DC Brake Select
Option: Function:
Select control of the DC brake via the terminals
(digital input) and/or via the eldbus.
NOTICE
When parameter 1-10 Motor Construction is
set to [1] PM non-salient SPM, only selection
[0] Digital input is available.
[0] Digital
input
Activates start command via a digital input.
[1] Bus Activates start command via the serial communi-
cation port or eldbus option.
[2] Logic
AND
Activates start command via the eldbus/serial
communication port, AND additionally via 1 of the
digital inputs.
[3] Logic OR Activates start command via the eldbus/serial
communication port OR via one of the digital
inputs.
8-53 Start Select
Option: Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the eldbus.
[0] Digital
input
Activates a start command via a digital input.
Parameter Descriptions Programming Guide
MG11CE02 Danfoss A/S © 03/2015 All rights reserved. 93
3 3
