The mains input cable should be CSA, UL, or CE approved, three-wire with a common shield and single
ground. The cable must be rated for 90°C (194°F) minimum at the maximum applicable current.
It is recommended that the cable be double-jacketed, e.g., teck cable type. Refer to "Table 6-4 Main
Cable Connector Plate Hole Sizes" for cable gland specifications.
Table 6-4 Main Cable Connector Plate Hole Sizes
6.14 Idle Power Consumption
TTS/TGS/TTH/TGH series have an Idle power consumption of 45 W.
Model 380V 400V 460V 575V
TTS300/TGS230 2.5" 2.5" 2.5” 2.5”
TTS350/TGS310 2.5" 2.5" 3” N/A
TTS400/TGS390 2.5" 2.5" 3” 3”
TGS490 2.5" 2.5" 3” N/A
TTS700/TGS520 2.5" 2.5" 3” N/A
TTH375/TGH285 2.5" 2.5" 3” N/A
NOTE
The plate hole sizes shown in Table 6-4 are standard production sizes for standard compressors released at the time of this
publication. OEMs have the flexibility to change those sizes according to their needs. Please refer to the Spare Parts Selection
Guide for more information on available sizes or contact your Key Account Manager for possible changes. If OEMs are ordering
compressors using the New Type Code configuration the mains plate connector size can be selected at the time of order.
