Danfoss VLT 2800 Design Guide

1. Select control card test.
2. Disconnect the mains voltage and wait until the
light in the display has disappeared.
3. Mount the control card.
4. Connect the mains voltage.
5. The frequency converter automatically tests the
control card.
If the frequency converter displays a fault code from 37-45,
the control card test has failed. Change the control card to
start up the frequency converter.
If the frequency converter enters Display mode, the test is
OK. Remove the test connector and the frequency
converter is ready for operation. Parameter 620 Operating
mode is automatically set to [0] Normal operation.
Select [3] Initialisation to use the unit's factory setting.
Procedure for initialisation:
1.
Select [3] Initialisation.
2. Disconnect the mains voltage and wait until the
light in the display has disappeared.
3. Connect the mains voltage.
4. An initialisation is performed in all parameters in
all set-ups, with the exception of parameters 500
Address, 501 Baudrate, 600-605 Operating data and
615-617 Fault log.
NOTICE
The control card is different on DeviceNet units. See the
DeviceNet manual for further details.
621-642 Nameplate data
Par. no Description Nameplate Display text
621 Unit type (DRIVE TYPE)
624 Software version (SOFTWARE VERSION)
625 LCP identification no. (LCP VERSION)
626 Database identification no. (DATABASE VER.)
627 Power parts version (POWER UNIT DB ID)
628 Application option type (APP. OPTION)
630 Communication option type (COM. OPTION)
632 BMC software identification (BMC-SOFTWARE ID)
634 Unit identification for communication (UNIT ID)
635 Software parts no. (SW. PART NO.)
640 Software version (SOFTWARE VERSION)
641 BMC-software identification (BMC2 SW)
642 Power card identification (POWER ID)
Table 4.43 Nameplate
Function:
The unit's main data can be read out from parameters 621
to 635 Nameplate using the LCP 2 control unit or serial
communication. Parameters 640 - 642 can also be seen on
the unit's integral display.
Description of choice:
Parameter 621 Nameplate: Unit type:
Gives unit size and mains voltage.
Example: VLT 2811 380-480 V.
Parameter 624 Nameplate: Software version no.
Shows the unit's present software version number.
Example: V 1.00
Parameter 625 Nameplate: LCP 2 ID number:
Shows the ID number of the unit's LCP 2.
Example: ID 1.42 2 kB
Parameter 626 Nameplate: Database ID number:
Shows the ID number of the software's database.
Example: ID 1.14.
Parameter 627 Nameplate: Power section version:
Shows the ID number of the unit's power section.
Example: ID 1.15.
Parameter 628 Nameplate: Application option type:
Specifies which types of application options are installed in
the frequency converter.
Parameter 630 Nameplate: Communication option type:
Specifies which types of communication options are
installed in the frequency converter.
Parameter 632 Nameplate: BMC software identification:
Shows the ID number of the BMC software.
Parameter 634 Nameplate: Unit identification for communi-
cation:
Shows the ID number for communication.
Parameter 635 Nameplate: Software section no.:
Shows the software section number.
Parameter 640 Nameplate: Software version:
The unit's present software version number appears here.
Example: 1.00
Parameter 641 Nameplate: BMC software identification:
Shows the ID number of the BMC software.
Parameter 642 Nameplate: Power card identification:
Shows the ID number of the unit's power part. Example:
1.15
Programming Design Guide
MG27E402 Danfoss A/S © Rev. May/2014 All rights reserved. 125
4 4
