copied to the frequency converter to which the control
panel is attached. Select [3] Download size-independent
parameter to download only the size-independent
parameters. This is used when downloading to a frequency
converter with a different rated power size than that from
which the parameter set-up originates.
NOTICE
Upload/download can only be performed in stop mode.
Download can only be performed to a adjustable
frequency drive with the same software version number,
see parameter 626 Database identification no.
008 Display scaling of output frequency
Value:
0.01 - 100.00
1.00
Function:
In this parameter, the factor is selected by which the
output frequency is to be multiplied. The value is shown in
the display, provided parameters 009-012 Display readout
have been set to [5] Output frequency x scaling.
Description of choice:
Set the required scaling factor.
009
Large display readout
Value:
No readout (none) [0]
Resulting reference [%]
(reference [%]) [1]
Resulting reference [unit]
(reference [unit]) [2]
Feedback [unit] (feedback [unit]) [3]
Frequency [Hz] (Frequency [Hz]) [4]
Output frequency x scaling
(frequency x scale) [5]
Motor current [A] (Motor current [A]) [6]
Torque [%] (Torque [%]) [7]
Power [kW] (Power [kW]) [8]
Power [HP] (Power [HP][US]) [9]
Motor voltage [V]
(Motor voltage [V]) [11]
DC link voltage [V]
(DC link voltage [V]) [12]
Thermal load motor [%]
(Motor thermal [%]) [13]
Thermal load [%]
(FC. thermal[%]) [14]
Running hours [Hours]
(RUNNING HOURS]) [15]
Digital input [Bin]
(Digital input[bin]) [16]
Analog input 53 [V]
(analog input 53 [V]) [17]
Analog input 60 [mA]
(analog input 60 [mA]) [19]
Pulse reference [Hz]
(Pulse ref. [Hz]) [20]
External reference [%]
(external ref. [%]) [21]
Status word [Hex] (Status word [hex]) [22]
Heatsink temperature [°C]
(Heatsink temp [°C]) [25]
Alarm word [Hex] (Alarm word [hex]) [26]
Control word [Hex] (Control word [Hex]) [27]
Warning word [Hex]
(warning word [Hex]) [28]
Extended status word [Hex]
(Ext. status [hex]) [29]
Communication option card warning
(COMM OPT WARN [HEX]) [30]
Pulse count
(PULSE COUNTER) [31]
Power [W]
(POWER [W]) [32]
Function:
Use this parameter to select the data value to display in
the LCP 2 control unit display line 2 when the frequency
converter is switched on. The display is also included in
the scrollbar in display mode. Use parameters 010-012
Display readout to select 3 more data values, which are
displayed in display line 1.
Description of choice:
No readout can only be selected in parameters 010-012
Small display readout.
Resulting reference [%] gives, as a percentage, the resulting
reference in the range from Minimum reference, Ref
MIN
to
Maximum reference, Ref
MAX
.
Reference [unit] gives the resulting reference with unit Hz
in Open loop. In Closed loop, the reference unit is selected
in parameter 416 Process units.
Feedback [unit] gives the resulting signal value using the
unit/scaling selected in parameter 414 Minimum feedback,
FB
LOW
, 415 Maximum feedback, FB
HIGH
and 416 Process units.
Frequency [Hz] gives the output frequency of the frequency
converter.
Output frequency x scaling [-] equals the present output
frequency f
M
multiplied by the factor set in parameter 008
Display scaling of output frequency.
Motor current [A] gives the phase current of the motor
measured as an effective value.
Torque [%] denotes the motor's present load in relation to
the motor's rated torque.
Power [kW] gives the present power that the motor is
absorbing in kW.
Power [HP] gives the present power that the motor is
absorbing in HP.
Motor voltage [V] gives the voltage supplied to the motor.
Programming
Design Guide
MG27E402 Danfoss A/S © Rev. May/2014 All rights reserved. 63
4 4
