Danfoss VLT AQUA Drive FC 202

FC 202
N355
N400
N450
Continuous kVA (at 460 V) [kVA]
430
470
470
540
540
582
Continuous kVA (at 480 V) [kVA]
468
511
511
587
587
632
Maximum input current
Continuous (at 400 V) [A]
578
634
634
718
670
771
Continuous (at 460/480 V) [A]
520
569
569
653
653
704
Maximum number and size of cables per phase
- Mains [mm
2
(AWG)]
4x127 (4x250 mcm)
4x127 (4x250 mcm)
4x127 (4x250 mcm)
- Mains with disconnect [mm
2
(AWG)]
4x127 (4x250 mcm)
4x127 (4x250 mcm)
4x127 (4x250 mcm)
- Mains with fusible disconnect [mm
2
(AWG)]
4x127 (4x250 mcm)
4x127 (4x250 mcm)
4x127 (4x250 mcm)
- Mains with contactor [mm
2
(AWG)]
4x127 (4x250 mcm)
4x127 (4x250 mcm)
4x127 (4x250 mcm)
- Motor [mm
2
(AWG)]
4x127 (4x250 mcm)
4x127 (4x250 mcm)
4x127 (4x250 mcm)
Drive module power loss at 400 V [W]
(1)(2)(3)
6178
6928
6851
8036
7297
8783
Drive module power loss at 460 V [W]
(1)(2)(3)
5322
5910
5846
6933
7240
7969
Drive eciency
(2)
0.98
0.98
0.98
Output frequency [Hz]
(4)
0–590
0–590
0–590
Heat sink overtemperature trip [°C (°F)]
110 (230)
110 (230)
110 (230)
Control card overtemperature trip [°C (°F)]
80 (176)
80 (176)
80 (176)
PHF overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
dU/dt lter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
Sine-wave lter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
1
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies to dimension-
ing of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control card power
consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-eciency-direc-
tive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each
add only 4 W.
2
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy eciency
class, see the Ambient Conditions section. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
3
See also Input Power Option Losses section.
4
If using an output lter, the output frequency is limited further. See the Motor Output (U, V, W) section.
Table 102: Electrical Data, Mains Supply 3x380–480 V AC
FC 202
N500
N560
High/normal overload
High overload=150% or 160% torque for a duration of 60 s. Normal overload=110%
torque for a duration of 60 s.
HO
NO
HO
NO
Typical shaft output at 400 V [kW]
450
500
500
560
Typical shaft output at 460 V [hp]
600
650
650
750
AQ262141056213en-000201 / 130R0882 | 145Danfoss A/S © 2020.09
Specications
VLT® AQUA Drive FC 202
Operating Guide
