Danfoss VLT AQUA Drive FC 202

Enclosure
Model
Impedance [%)
D10h
N250
3.67
D10h
N315
3.08
D10h
N355
3.67
E5h
N400
2.89
E5h
N500
3.11
E5h
N560
3.55
E5h
N630
4.04
E6h
N710
3.19
E6h
N800
3.70
10.7.3 dU/dt Filter Specications
Voltage rating
3x380–690 V
Motor frequency derating, 50 Hz
Nominal
Motor frequency derating, 60 Hz
Nominal
Motor frequency derating, 100 Hz
0.75 x nominal
Minimum switching frequency
No limit
Maximum switching frequency
Nominal switching frequency
Overload capacity
150% for 60 s, every 10 minutes
10.7.4 Sine-wave Filter Specications
Voltage rating
3x380–480 V and 525–690 V AC
Nominal current @ 50 Hz
212 A and 315 A for 380–480 V, 137 A and 222 A for 525–690 V
(1)
Motor frequency with derating
(1)
Up to 150 Hz
Motor frequency without derating
0–60 Hz
Minimum switching frequency
2 kHz for 380–480 V, 1.5 kHz for 525–690 V
Maximum switching frequency
Nominal switching frequency
Overvoltage category
OVC III as dened in IEC61800-5-1
Overload capacity
150% for 60 s every 10 minutes
Ambient temperature [°C (°F)]
(2)
-15 (5) to +60 (140)
Storage temperature [°C (°F)]
-40 (-40) to +70 (158)
Transport temperature [°C (°F)]
-40 (-40) to +70 (158)
Altitude during operation
100% current (no derating) up to 1000 m (3280 ft)
1% current derating for each 100 m (328 ft) above 1000 m
(3280 ft)
Maximum 4000 m (13123 ft) with 500 V AC
Maximum 2000 m (6561 ft) with 690 V AC
Noise level
< 80 dB(A)
1
The current ratings for the E5h and E6h enclosures are achieved by lter paralleling.
2
See
Illustration 71.
