Minimum output frequency at frequency output
Maximum output frequency at frequency output
Accuracy of frequency output
Maximum error: 0.1% of full scale
Resolution of frequency outputs
1
Can also be programmed as input.
The digital output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
10.6.6 Digital Inputs
Programmable digital inputs
XD2.12, XD2.13, XD2.14, XD2.15, XD2.16, XD2.17
Voltage level, logic 0 PNP
Voltage level, logic 1 PNP
Voltage level, logic 0 NPN
(2)
Voltage level, logic 1 NPN
(2)
(Duty cycle) minimum pulse width
1
Terminals XD2.14 and XD2.15 can also be programmed as output.
2
Except STO input terminal XD2.19.
All digital inputs are galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
10.6.7 Pulse/Encoder Inputs
Programmable pulse/encoder inputs
Terminal number (pulse inputs)
Terminal number (encoder inputs)
(2)
Maximum frequency at terminals XD2.15, XD2.16, XD2.17 (push-
pull driven)
Maximum frequency at terminals XD2.15, XD2.16, XD2.17 (open
collector)
Maximum frequency at terminals XD2.15, XD2.16, XD2.17
See Control Input/Output and Control Data.
Pulse input accuracy (0.1–1 kHz)
Maximum error: 0.1% of full scale
Encoder input accuracy (1–11 kHz)
Maximum error: 0.05% of full scale
2
Encoder inputs: XD2.16=A, XD2.17=B.
The pulse and encoder inputs (terminals XD2.15, XD2.16, XD2.17) are galvanically isolated from the supply voltage (PELV) and other
high-voltage terminals.
10.6.8 Control Characteristics
Resolution of output frequency at 0–590 Hz
