Danfoss VLT AQUA Drive FC 202

•
•
•
•
•
•
3.6.4 LCP Menu
Quick Menus
The Quick Menus mode provides a list of menus used to congure and operate the drive. Select the Quick Menus mode by pressing
the [Quick Menu] key. The resulting readout appears on the LCP display.
e30bf242.10
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
0.0% 0.00
Quick Menus
1(1)
Illustration 10: Quick Menu View
Q1 My Personal Menu
The Personal Menu is used to determine what is shown in the display area. Refer to 3.6.3 Local Control Panel (LCP). This menu can
also show up to 50 pre-programmed parameters. These 50 parameters are manually entered using parameter 0-25 My Personal
Menu.
Q2 Quick Setup
The parameters found in the Q2 Quick Setup contain basic system and motor data that are always necessary for conguring the
drive. See
7.2.4 Entering System Information for the set-up procedures.
Q3 Function Setups
The parameters found in the Q3 Function Setups contain data for fan, compressor, and pump functions. This menu also includes
parameters for LCP display, digital preset speeds, scaling of analog references, closed-loop single-zone, and multizone applications.
Q4 Smart Setup
Q4 Smart Setup guides the user through typical parameter settings used to congure 1 of the following 4 applications:
Single pump/motor.
Motor alternation.
Master/follower.
Basic cascade.
The [Info] key can be used to see help information for various selections, settings, and messages.
Q5 Changes Made
Select Q5 Changes Made for information about:
The 10 most recent changes.
Changes made from default setting.
Q6 Loggings
Use Q6 Loggings for fault nding. To get information about the display line readout, select Loggings. The information is shown as
graphs. Only parameters selected in parameter 0-20 Display Line 1.1 Small through parameter 0-24 Display Line 3 Large can be viewed.
It is possible to store up to 120 samples in the memory for later reference.
Table 38: Logging Parameter Examples
Q6 Loggings
Parameter 0-20 Display Line 1.1 Small
Reference [Unit]
Parameter 0-21 Display Line 1.2 Small
Analog input 53 [V]
Parameter 0-22 Display Line 1.3 Small
Motor current [A]
Parameter 0-23 Display Line 2 Large
Frequency [Hz]
Parameter 0-24 Display Line 3 Large
Feedback [Unit]
AQ262141056213en-000201 / 130R088232 | Danfoss A/S © 2020.09
Product Overview
VLT® AQUA Drive FC 202
Operating Guide
