Danfoss VLT AQUA Drive FC 202

FC 202
N200
N250
N315
- Mains with fusible disconnect [mm
2
(AWG)]
2x185 (2x350 mcm)
2x185 (2x350 mcm)
2x185 (2x350 mcm)
- Mains with contactor [mm
2
(AWG)]
2x185 (2x350 mcm)
2x185 (2x350 mcm)
2x185 (2x350 mcm)
- Mains [mm
2
(AWG)]
2x185 (2x350 mcm)
2x185 (2x350 mcm)
2x185 (2x350 mcm)
Drive module power loss at 400 V [W]
(1)(2)(3)
3093
4116
4039
5137
5005
6674
Drive module power loss at 460 V [W]
(1)(2)(3)
2872
3569
3575
4566
4458
5714
Drive eciency
(2)
0.98
0.98
0.98
Output frequency [Hz]
(4)
0–590
0–590
0–590
Heat sink overtemperature trip [°C (°F)]
110 (230)
110 (230)
110 (230)
Control card overtemperature trip [°C (°F)]
80 (176)
80 (176)
80 (176)
PHF overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
dU/dt lter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
Sine-wave lter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
1
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies to dimension-
ing of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control card power
consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-eciency-direc-
tive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each
add only 4 W.
2
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy eciency
class, see the Ambient Conditions section. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
3
See also Input Power Option Losses section.
4
If using an output lter, the output frequency is limited further. See the Motor Output (U, V, W) section.
Table 101: Electrical Data, Mains Supply 3x380–480 V AC
FC 202
N355
N400
N450
High/normal overload
High overload=150% or 160% torque for a duration of 60 s.
Normal overload=110% torque for a duration of 60 s.
HO
NO
HO
NO
HO
NO
Typical shaft output at 400 V [kW]
315
355
355
400
400
450
Typical shaft output at 460 V [hp]
450
500
500
600
550
600
Typical shaft output at 480 V [kW]
355
400
400
500
500
530
Enclosure size
E5h
E5h
E5h
Output current (3-phase)
Continuous (at 400 V) [A]
600
658
658
745
695
800
Intermittent (60 s overload) (at 400 V) [A]
900
724
987
820
1043
880
Continuous (at 460/480 V) [A]
540
590
590
678
678
730
Intermittent (60 s overload) (at 460/480 V) [A]
810
649
885
746
1017
803
Continuous kVA (at 400 V) [kVA]
416
456
456
516
482
554
AQ262141056213en-000201 / 130R0882144 | Danfoss A/S © 2020.09
Specications
VLT® AQUA Drive FC 202
Operating Guide
