FC 202
N110
N132
N160
Control card overtemperature trip [°C (°F)]
75 (167)
75 (167)
75 (167)
PHF overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
dU/dt lter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
Sine-wave lter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
1
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies to dimension-
ing of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control card power
consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-eciency-direc-
tive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each
add only 4 W.
2
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy eciency
class, see the Ambient Conditions section. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
3
See also Input Power Option Losses section.
4
If using an output lter, the output frequency is limited further. See the Motor Output (U, V, W) section.
Table 100: Electrical Data, Mains Supply 3x380–480 V AC
FC 202
N200
N250
N315
High/normal overload
High overload=150% or 160% torque for a duration of 60 s.
Normal overload=110% torque for a duration of 60 s.
HO
NO
HO
NO
HO
NO
Typical shaft output at 400 V [kW]
160
200
200
250
250
315
Typical shaft output at 460 V [hp]
250
300
300
350
350
450
Typical shaft output at 480 V [kW]
200
250
250
315
315
355
Enclosure size
D10h
D10h
D10h
Output current (3-phase)
Continuous (at 400 V) [A]
315
395
395
480
480
588
Intermittent (60 s overload) (at 400 V) [A]
473
435
593
528
720
647
Continuous (at 460/480 V) [A]
302
361
361
443
443
535
Intermittent (60 s overload) (at 460/480 V) [A]
453
397
542
487
665
589
Continuous kVA (at 400 V) [kVA]
218
274
274
333
333
407
Continuous kVA (at 460 V) [kVA]
241
288
288
353
353
426
Continuous kVA (at 480 V) [kVA]
262
313
313
384
384
463
Maximum input current
Continuous (at 400 V) [A]
304
381
381
463
463
567
Continuous (at 460/480 V) [A]
291
348
348
427
427
516
Maximum number and size of cables per phase
- Mains [mm
2
(AWG)]
2x185 (2x350 mcm)
2x185 (2x350 mcm)
2x185 (2x350 mcm)
- Mains with disconnect [mm
2
(AWG)]
2x185 (2x350 mcm)
2x185 (2x350 mcm)
2x185 (2x350 mcm)
AQ262141056213en-000201 / 130R0882 | 143Danfoss A/S © 2020.09
Specications
VLT® AQUA Drive FC 202
Operating Guide
