Danfoss VLT AQUA Drive FC 202

FC 202
N450
N500
N560
Enclosure size
E5h
E5h
E5h
Output current (3-phase)
Continuous (at 550 V) [A]
395
470
429
523
523
596
Intermittent (60 s overload) (at 550 V) [A]
593
517
644
575
785
656
Continuous (at 575/690 V) [A]
380
450
410
500
500
570
Intermittent (60 s overload) (at 575/690 V) [A]
570
495
615
550
750
627
Continuous kVA (at 550 V) [kVA]
376
448
409
498
498
568
Continuous kVA (at 575 V) [kVA]
378
448
408
498
498
568
Continuous kVA (at 690 V) [kVA]
454
538
490
598
598
681
Maximum input current
Continuous (at 525 V) [A]
381
453
413
504
504
574
Continuous (at 575/690 V) [A]
366
434
395
482
482
549
Maximum number and size of cables per phase
- Mains [mm
2
(AWG)]
4x127 (4x250 mcm)
4x127 (4x250 mcm)
4x127 (4x250 mcm)
- Mains with disconnect [mm
2
(AWG)]
4x127 (4x250)
4x127 (4x250)
4x127 (4x250)
- Mains with fusible disconnect [mm
2
(AWG)]
4x127 (4x250)
4x127 (4x250)
4x127 (4x250)
- Mains with contactor [mm
2
(AWG)]
4x127 (4x250)
4x127 (4x250)
4x127 (4x250)
- Motor [mm
2
(AWG)]
4x127 (4x250)
4x127 (4x250)
4x127 (4x250)
Drive module power loss at 600 V [W]
(1)(2)(3)
4989
6062
5419
6879
6833
8076
Drive module power loss at 690 V [W]
(1)(2)(3)
4920
5939
5332
6715
6678
7852
Drive eciency
(2)
0.98
0.98
0.98
Output frequency [Hz]
(4)
0–500
0–500
0–500
Heat sink overtemperature trip [°C (°F)]
110 (230)
110 (230)
110 (230)
Control card overtemperature trip [°C (°F)]
80 (176)
80 (176)
80 (176)
PHF overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
dU/dt lter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
AQ262141056213en-000201 / 130R0882150 | Danfoss A/S © 2020.09
Specications
VLT® AQUA Drive FC 202
Operating Guide
