Danfoss VLT AQUA Drive FC 202

FC 202
N250
N315
N400
Continuous kVA (at 690 V) [kVA]
289
347
347
411
411
478
Maximum input current
Continuous (at 525 V) [A]
244
292
292
347
347
403
Continuous (at 575/690 V) [A]
233
279
279
332
332
385
Maximum number and size of cables per phase
- Mains [mm
2
(AWG)]
2x185 (2x350 mcm)
2x185 (2x350 mcm)
2x185 (2x350 mcm)
- Mains with disconnect [mm
2
(AWG)]
2x185 (2x350 mcm)
2x185 (2x350 mcm)
2x185 (2x350 mcm)
- Mains with fusible disconnect [mm
2
(AWG)]
2x185 (2x350 mcm)
2x185 (2x350 mcm)
2x185 (2x350 mcm)
- Mains with contactor [mm
2
(AWG)]
2x185 (2x350 mcm)
2x185 (2x350 mcm)
2x185 (2x350 mcm)
- Motor [mm
2
(AWG)]
2x185 (2x350 mcm)
2x185 (2x350 mcm)
2x185 (2x350 mcm)
Drive module power loss at 600 V [W]
(1)(2)(3)
3012
3723
3642
4465
4146
5028
Drive module power loss at 690 V [W]
(1)(2)(3)
3123
3851
3771
4614
4258
5155
Drive eciency
(2)
0.98
0.98
0.98
Output frequency [Hz]
(4)
0–590
0–590
0–590
Heat sink overtemperature trip [°C (°F)]
110 (230)
110 (230)
110 (230)
Control card overtemperature trip [°C (°F)]
80 (176)
80 (176)
80 (176)
PHF overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
dU/dt lter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
Sine-wave lter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
1
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies to dimension-
ing of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control card power
consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-eciency-direc-
tive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each
add only 4 W.
2
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy eciency
class, see the Ambient Conditions section. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
3
See also Input Power Option Losses section.
4
If using an output lter, the output frequency is limited further. See the Motor Output (U, V, W) section.
Table 105: Electrical Data, Mains Supply 3x525–690 V AC
FC 202
N450
N500
N560
High/normal overload
High overload=150% or 160% torque for a duration of 60 s.
Normal overload=110% torque for a duration of 60 s.
HO
NO
HO
NO
HO
NO
Typical shaft output at 550 V [kW]
315
355
355
400
400
450
Typical shaft output at 575 V [hp]
400
450
400
500
500
600
Typical shaft output at 690 V [kW]
355
450
400
500
500
560
AQ262141056213en-000201 / 130R0882 | 149Danfoss A/S © 2020.09
Specications
VLT® AQUA Drive FC 202
Operating Guide
