Danfoss VLT AQUA Drive FC 202

Power derating
Same as drive
Table 107: Displacement Power Factor (Cos Phi)
Load [%]
Automatic capacitor control [p.u.]
(1)(2)
Capacitor always connected [p.u.]
(1)
Capacitor always open [p.u.]
(1)
10
1.000
-0.790
1.000
25
-0.830
-0.830
0.990
50
-0.996
-0.996
0.950
75
0.997
0.997
0.930
100
0.986
0.986
0.920
160
0.980
0.980
0.910
1
Positive numbers indicate lagging reactive currents. Negative numbers indicate leading currents.
2
The capacitor connecting contactor switches at 20% load.
10.7.2 Line Reactor Specications
All line reactors are equipped with thermal switches and are looped to the enclosed drive for overtemperature protection. For more
details, refer to the Control Compartment section. The line reactor conguration varies depending on the enclosure and voltage re-
quired.
Table 108: Line Reactor Conguration for D9h–D10h and E5h–E6h Enclosures, 380–480 V
Enclosure
Model
Impedance [%]
D9h
N110
2.70
D9h
N132
3.22
D9h
N160
2.87
D10h
N200
3.47
D10h
N250
3.01
D10h
N315
3.65
E5h
N355
3.30
E5h
N400
3.62
E5h
N450
3.83
E6h
N500
2.94
E6h
N560
3.23
Table 109: Line Reactor Conguration for D9h–D10h and E5h–E6h Enclosures, 525–690 V
Enclosure
Model
Impedance [%)
D9h
N110
2.30
D9h
N132
2.78
D9h
N160
3.29
D10h
N200
2.92
