Danfoss VLT AQUA Drive FC 202

FC 202
N110
N132
N160
N200
- Mains with contactor [mm
2
(AWG)]
2x95 (2x3/0 mcm)
2x95 (2x3/0 mcm)
2x95 (2x3/0 mcm)
2x185 (2x350 mcm)
- Motor [mm
2
(AWG)]
2x95 (2x3/0 mcm)
2x95 (2x3/0 mcm)
2x95 (2x3/0 mcm)
2x185 (2x350 mcm)
Drive module power loss at 600 V [W]
(1)(2)(3)
1430
1740
1742
2101
2080
2649
2361
3074
Drive module power loss at 690 V [W]
(1)(2)(3)
1480
1798
1800
2167
2159
2740
2446
3175
Drive eciency
(2)
0.98
0.98
0.98
0.98
Output frequency [Hz]
(4)
0–590
0–590
0–590
0–590
Heat sink overtemperature trip [°C (°F)]
110 (230)
110 (230)
110 (230)
110 (230)
Control card overtemperature trip [°C (°F)]
75 (167)
75 (167)
75 (167)
75 (167)
PHF overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
150 (302)
dU/dt lter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
150 (302)
Sine-wave lter overtemperature trip [°C (°F)]
150 (302)
150 (302)
150 (302)
150 (302)
1
Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions.) These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies to dimension-
ing of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control card power
consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-eciency-direc-
tive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each
add only 4 W.
2
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy eciency
class, see the Ambient Conditions section. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
3
See also Input Power Option Losses section.
4
If using an output lter, the output frequency is limited further. See the Motor Output (U, V, W) section.
Table 104: Electrical Data, Mains Supply 3x525–690 V AC
FC 202
N250
N315
N400
High/normal overload
High overload=150% or 160% torque for a duration of 60 s.
Normal overload=110% torque for a duration of 60 s.
HO
NO
HO
NO
HO
NO
Typical shaft output at 550 V [kW]
160
200
200
250
250
315
Typical shaft output at 575 V [hp]
250
300
300
350
350
400
Typical shaft output at 690 V [kW]
200
250
250
315
315
400
Enclosure size
D10h
D10h
D10h
Output current (3-phase)
Continuous (at 550 V) [A]
395
303
303
360
360
418
Intermittent (60 s overload) (at 550 V) [A]
380
333
455
396
540
460
Continuous (at 575/690 V) [A]
242
290
290
344
344
400
Intermittent (60 s overload) (at 575/690 V) [A]
363
319
435
378
516
440
Continuous kVA (at 550 V) [kVA]
230
276
276
327
327
380
Continuous kVA (at 575 V) [kVA]
241
289
289
343
343
398
AQ262141056213en-000201 / 130R0882148 | Danfoss A/S © 2020.09
Specications
VLT® AQUA Drive FC 202
Operating Guide
