Danfoss VLT AQUA Drive FC 202

Table 47: Option A Terminal Connections for VLT® DeviceNet MCA 104, VLT® CANopen MCA 105, VLT® DeviceNet Converter MCA 194
Option card terminal
Corresponding terminal within the control compartment
1
XD2.40
2
XD2.41
3
XD2.42
4
XD2.43
5
XD2.44
Table 48: Option A Terminal Connections for VLT® PROFIBUS DP-V1 MCA 101, VLT® PROFIBUS Converter VLT 300 MCA 113, VLT® PROFIBUS Con-
verter VLT 5000 MCA 114
Option card terminal
Corresponding terminal within the control compartment
67
XD2.40
66
XD2.41
63
XD2.42
62
XD2.43
CS
XD2.44
Table 49: Option A Terminal Connections for VLT® EtherNet/IP MCA 121, VLT® Modbus TCP MCA 122, VLT® POWERLINK MCA 123, VLT® EtherCAT
MCA 124
Option card terminal
Corresponding terminal within the control compartment
Port 1
RJ45_1
Port 2
RJ45_2
Table 50: Option B Terminal Connections
Option card terminal
Corresponding terminal within the control compartment
1
XD2.46
2
XD2.47
3
XD2.48
4
XD2.49
5
XD2.50
6
XD2.51
7
XD2.52
8
XD2.53
9
XD2.54
10
XD2.55
11
XD2.56
12
XD2.57
AQ262141056213en-000201 / 130R088272 | Danfoss A/S © 2020.09
Electrical Installation
VLT® AQUA Drive FC 202
Operating Guide
