Danfoss VLT AQUA Drive FC 202 Operating Manual

Enclosure size D5h D6h D7h D8h
Rated power [kW]
110–160 kW
(380–480 V)
75–160 kW
(525–690 V)
110–160 kW
(380–480 V)
75–160 kW
(525–690 V)
200–315 kW
(380–480 V)
200–400 kW
(525–690 V)
200–315 kW
(380–480 V)
200–400 kW
(525–690 V)
IP
NEMA
21/54
Type 1/12
21/54
Type 1/12
21/54
Type 1/12
21/54
Type 1/12
Shipping dimensions
[mm (inch)]
Height 1805 (71) 1805 (71) 2490 (98) 2490 (98)
Width 510 (20) 510 (20) 585 (23) 585 (23)
Depth 635 (25) 635 (25) 640 (25) 640 (25)
Drive dimensions [mm
(inch)]
Height 1324 (52) 1665 (66) 1978 (78) 2284 (90)
Width 325 (13) 325 (13) 420 (17) 420 (17)
Depth 381 (15) 381 (15) 386 (15) 406 (16)
Maximum weight [kg (lb)] 449 (990) 449 (990) 530 (1168) 530 (1168)
Table 3.2 Power Ratings, Weight, and Dimensions, Enclosure Size D5h–D8h
