3 Product Overview
3.1 Intended Use
The drive is an electronic motor controller that converts AC mains input into a variable AC waveform output. The frequency
and voltage of the output are regulated to control the motor speed or torque. The drive is designed to:
•
Regulate motor speed in response to system feedback or to remote commands from external controllers.
•
Monitor system and motor status.
•
Provide motor overload protection.
The drive is designed for industrial and commercial environments in accordance with local laws and standards. Depending
on conguration, the drive can be used in standalone applications or form part of a larger system or installation.
NOTICE
In a residential environment, this product can cause radio interference, in which case supplementary mitigation
measures can be required.
Foreseeable misuse
Do not use the drive in applications which are non-compliant with specied operating conditions and environments. Ensure
compliance with the conditions specied in chapter 10 Specications.
3.2 Power Ratings, Weight, and Dimensions
For enclosure sizes and power ratings of the drives, refer to Table 3.1. For more dimensions, see chapter 10.9 Enclosure
Dimensions.
Enclosure size D1h D2h D3h D4h D3h D4h
Rated power [kW]
55–75 kW
(200–240 V)
110–160 kW
(380–480 V)
75–160 kW
(525–690 V)
90–160 kW
(200–240 V)
200–315 kW
(380–480 V)
200–400 kW
(525–690 V)
55–75 kW
(200–240 V)
110–160 kW
(380–480 V)
75–160 kW
(525–690 V)
90–160 kW
(200–240 V)200–
315 kW
(380–480 V)
200–400 kW
(525–690 V)
With regeneration or load share
terminals
1)
IP
NEMA
21/54
Type 1/12
21/54
Type 1/12
20
Chassis
20
Chassis
20
Chassis
20
Chassis
Shipping
dimensions
[mm (inch)]
Height 587 (23) 587 (23) 587 (23) 587 (23) 587 (23) 587 (23)
Width 997 (39) 1170 (46) 997 (39) 1170 (46) 1230 (48) 1430 (56)
Depth 460 (18) 535 (21) 460 (18) 535 (21) 460 (18) 535 (21)
Drive
dimensions
[mm (inch)]
Height 893 (35) 1099 (43) 909 (36) 1122 (44) 1004 (40) 1268 (50)
Width 325 (13) 420 (17) 250 (10) 350 (14) 250 (10) 350 (14)
Depth 378 (15) 378 (15) 375 (15) 375 (15) 375 (15) 375 (15)
Maximum weight [kg (lb)] 98 (216) 164 (362) 98 (216) 164 (362) 108 (238) 179 (395)
Table 3.1 Power Ratings, Weight, and Dimensions, Enclosure Size D1h–D4h
1) Regen, load share, and brake terminal options are not available for 200–240 V drives.
Product Overview Operating Guide
MG21A502 Danfoss A/S © 09/2018 All rights reserved. 7
3 3
