Danfoss VLT AQUA Drive FC 202

5.8 Terminal Dimensions
5.8.1 D1h Terminal Dimensions
88 (3.5)
0.0
200 (7.9)
130BF342.10
0.0
94 (3.7)
293 (11.5) 263 (10.4)
33 (1.3) 62 (2.4)
101 (4.0) 140 (5.5) 163 (6.4) 185 (7.3) 224 (8.8)
2
1
3
1 Mains terminals 3 Motor terminals
2 Ground terminals – –
Illustration 5.7 D1h Terminal Dimensions (Front View)
Electrical Installation Operating Guide
MG21A502 Danfoss A/S © 09/2018 All rights reserved. 35
5 5
