Danfoss VLT AQUA Drive FC 202 Operating Manual

e30bg485.10
244 (9.6)
101 (4.0)
125 (4.9)
14 (0.6)
32 (1.3)
16 (0.6)
125 (4.9)
95 (3.7)
236 (9.3)
87 (3.4)
1
2
3
6
7
8
9
11
4
5
10
12
1 Top openings for regen/load share terminals 7 DC(+) terminal
2 Terminal cover 8 DC(-) terminal
3 Side opening for regen/load share terminals 9 Hole for M10 fastener
4 Top view 10 Close-up view
5 Side view 11 Regen/load share terminals
6 View without cover 12 Front view
Illustration 5.6 Regen/Load Share Terminals in Enclosure Size D
