3.5 View of Control Shelf
The control shelf holds the keypad, known as the local control panel or LCP. The control shelf also includes the control
terminals, relays, and various connectors.
1 Local control panel (LCP) 7 Mounting holes
2 RS485 termination switch 8 LCP connector
3 USB connector 9 Analog switches (A53, A54)
4 RS485 eldbus connector 10 Analog I/O connector
5 Digital I/O and 24 V supply 11 Relay 1 (01, 02, 03) on power card
6 Lifting rings 12 Relay 2 (04, 05, 06) on power card
Illustration 3.3 View of Control Shelf
Product Overview Operating Guide
MG21A502 Danfoss A/S © 09/2018 All rights reserved. 11
3 3
