Danfoss VLT AQUA Drive FC 202 Operating Manual

Parameters
+10
V
A IN
A IN
COM
A OUT
COM
50
53
54
55
42
39
+
-
FC
e30bb927.11
A53
U - I
4 - 20mA
Function Setting
Parameter 6-12
Terminal 53 Low
Current
4 mA*
Parameter 6-13
Terminal 53
High Current
20 mA*
Parameter 6-14
Terminal 53 Low
Ref./Feedb.
Value
0 RPM
Parameter 6-15
Terminal 53
High Ref./Feedb.
Value
1500 RPM
*=Default value
Notes/comments:
Table 8.4 Wiring Conguration for Analog Speed Reference
(Current)
8.3
Wiring Congurations for Start/Stop
Parameters
FC
+24 V
+24 V
D IN
D IN
D IN
COM
D IN
D IN
D IN
D IN
+10
A IN
A IN
COM
A OUT
COM
12
13
18
19
20
27
29
32
33
37
50
53
54
55
42
39
130BB802.10
Function Setting
Parameter 5-10 T
erminal 18
Digital Input
[8] Start*
Parameter 5-12 T
erminal 27
Digital Input
[0] No
operation
Parameter 5-19 T
erminal 37
Digital Input
[1] Safe
Torque O
Alarm
*=Default value
Notes/comments:
If parameter 5-12 Terminal 27
Digital Input is set to [0] No
operation, a jumper wire to
terminal 27 is not needed.
Table 8.5 Wiring Conguration for Start/Stop Command with
Safe Torque O
130BB805.12
Speed
Start/Stop (18)
Illustration 8.1 Start/Stop with Safe Torque O
Parameters
FC
+24 V
+24 V
D IN
D IN
D IN
COM
D IN
D IN
D IN
D IN
+10 V
A IN
A IN
COM
A OUT
COM
12
13
18
19
20
27
29
32
33
37
50
53
54
55
42
39
130BB803.10
Function Setting
Parameter 5-10
Terminal 18
Digital Input
[9] Latched
Start
Parameter 5-12
Terminal 27
Digital Input
[6] Stop Inverse
*=Default value
Notes/comments:
If parameter 5-12 Terminal 27
Digital Input is set to [0] No
operation, a jumper wire to
terminal 27 is not needed.
Table 8.6 Wiring Conguration for Pulse Start/Stop
Speed
130BB806.10
Latched Start (18)
Stop Inverse (27)
Illustration 8.2 Latched Start/Stop Inverse
Wiring Conguration Exampl... VLT® AQUA Drive FC 202
74 Danfoss A/S © 09/2018 All rights reserved. MG21A502
