Danfoss VLT AQUA Drive FC 202

200 (7.9)
246 (9.7)
893
(35.2)
656
(25.8)
200 (7.9)
844
(33.2)
130 (5.1)
180 (7.1)
325 (12.8)
123
(4.8)
78
(3.1)
63 (2.5)
11
(0.4)
20
(0.8)
9
(0.3)
24
(0.9)
33
(1.3)
25
(1.0)
11 (0.4)
130BF798.10
A
A
B
B
Illustration 10.4 Back View of D1h
Specications Operating Guide
MG21A502 Danfoss A/S © 09/2018 All rights reserved. 115
10 10
