Danfoss VLT AQUA Drive FC 202

6-2* Analog Input 54
6-20 Terminal 54 Low Voltage
6-21 Terminal 54 High Voltage
6-22 Terminal 54 Low Current
6-23 Terminal 54 High Current 6-24 Terminal 54 Low Ref./Feedb. Value 6-25 Terminal 54 High Ref./Feedb. Value 6-26 Terminal 54 Filter Time Constant 6-27 Terminal 54 Live Zero
6-3* Analog Input X30/11 6-30 Terminal X30/11 Low Voltage 6-31 Terminal X30/11 High Voltage 6-34 Term. X30/11 Low Ref./Feedb. Value
6-35 Term. X30/11 High Ref./Feedb. Value
6-36 Term. X30/11 Filter Time Constant
6-37 Term. X30/11 Live Zero
6-4* Analog Input X30/12 6-40 Terminal X30/12 Low Voltage 6-41 Terminal X30/12 High Voltage 6-44 Term. X30/12 Low Ref./Feedb. Value
6-45 Term. X30/12 High Ref./Feedb. Value
6-46 Term. X30/12 Filter Time Constant
6-47 Term. X30/12 Live Zero
6-5* Analog Output 42
6-50 Terminal 42 Output
6-51 Terminal 42 Output Min Scale
6-52 Terminal 42 Output Max Scale 6-53 Terminal 42 Output Bus Control
6-54 Terminal 42 Output Timeout Preset
6-55 Terminal 42 Output Filter
6-6* Analog Output X30/8 6-60 Terminal X30/8 Output
6-61 Terminal X30/8 Min. Scale
6-62 Terminal X30/8 Max. Scale 6-63 Terminal X30/8 Output Bus Control
6-64 Terminal X30/8 Output Timeout Preset
6-7* Analog Output X45/1 6-70 Terminal X45/1 Output
6-71 Terminal X45/1 Min. Scale
6-72 Terminal X45/1 Max. Scale 6-73 Terminal X45/1 Bus Control
6-74 Terminal X45/1 Output Timeout Preset
6-8* Analog Output X45/3 6-80 Terminal X45/3 Output
6-81 Terminal X45/3 Min. Scale
6-82 Terminal X45/3 Max. Scale 6-83 Terminal X45/3 Bus Control
6-84 Terminal X45/3 Output Timeout Preset
8-** Comm. and Options 8-0* General Settings 8-01 Control Site 8-02 Control Source 8-03 Control Timeout Time
8-04 Control Timeout Function
8-05 End-of-Timeout Function
8-06 Reset Control Timeout 8-07 Diagnosis Trigger 8-08 Readout Filtering
8-1* Control Settings
8-10 Control Prole 8-13 Congurable Status Word STW 8-14 Congurable Control Word CTW 8-17 Congurable Alarm and Warningword 8-3* FC Port Settings 8-30 Protocol 8-31 Address 8-32 Baud Rate 8-33 Parity / Stop Bits 8-35 Minimum Response Delay 8-36 Max Response Delay
8-37 Maximum Inter-Char Delay
8-4* FC MC protocol set 8-40 Telegram Selection 8-42 PCD Write Conguration 8-43 PCD Read Conguration 8-5* Digital/Bus 8-50 Coasting Select 8-51 Quick Stop Select 8-52 DC Brake Select
8-53 Start Select 8-54 Reversing Select 8-55 Set-up Select
8-56 Preset Reference Select
8-8* FC Port Diagnostics 8-80 Bus Message Count 8-81 Bus Error Count
8-82 Slave Message Rcvd
8-83 Slave Error Count
8-9* Bus Jog / Feedback 8-94 Bus Feedback 1
8-95 Bus Feedback 2
8-96 Bus Feedback 3 8-97 Response Error Codes
9-** PROFIdrive 9-00 Setpoint 9-07 Actual Value 9-15 PCD Write Conguration 9-16 PCD Read Conguration 9-18 Node Address 9-22 Telegram Selection 9-23 Parameters for Signals
9-27 Parameter Edit 9-28 Process Control 9-31 Safe Address 9-44 Fault Message Counter
9-45 Fault Code
9-47 Fault Number
9-52 Fault Situation Counter 9-53 Probus Warning Word
9-63 Actual Baud Rate 9-64 Device Identication 9-65 Prole Number 9-67 Control Word 1
9-68 Status Word 1 9-70 Programming Set-up
9-71 Probus Save Data Values
9-72 ProbusDriveReset 9-75 DO Identication
9-80 Dened Parameters (1) 9-81 Dened Parameters (2) 9-82 Dened Parameters (3) 9-83 Dened Parameters (4) 9-84 Dened Parameters (5) 9-85 Dened Parameters (6) 9-90 Changed Parameters (1)
9-91 Changed Parameters (2)
9-92 Changed Parameters (3)
9-93 Changed Parameters (4) 9-94 Changed Parameters (5)
9-99 Probus Revision Counter
10-** CAN Fieldbus 10-0* Common Settings 10-00 CAN Protocol 10-01 Baud Rate Select
10-02 MAC ID 10-05 Readout Transmit Error Counter 10-06 Readout Receive Error Counter 10-07 Readout Bus O Counter
10-1* DeviceNet 10-10 Process Data Type Selection
10-11 Process Data Cong Write
10-12 Process Data Cong Read
10-13 Warning Parameter 10-14 Net Reference 10-15 Net Control
10-2* COS Filters 10-20 COS Filter 1 10-21 COS Filter 2
10-22 COS Filter 3 10-23 COS Filter 4
10-3* Parameter Access
10-30 Array Index
10-31 Store Data Values
10-32 Devicenet Revision
10-33 Store Always
10-34 DeviceNet Product Code
10-39 Devicenet F Parameters
12-** Ethernet 12-0* IP Settings 12-00 IP Address Assignment
12-01 IP Address
12-02 Subnet Mask 12-03 Default Gateway
12-04 DHCP Server 12-05 Lease Expires 12-06 Name Servers 12-07 Domain Name 12-08 Host Name 12-09 Physical Address
12-1* Ethernet Link Parameters 12-10 Link Status 12-11 Link Duration 12-12 Auto Negotiation
12-13 Link Speed 12-14 Link Duplex
12-18 Supervisor MAC 12-19 Supervisor IP Addr.
12-2* Process Data 12-20 Control Instance 12-21 Process Data Cong Write
12-22 Process Data Cong Read
12-27 Primary Master 12-28 Store Data Values 12-29 Store Always
12-3* EtherNet/IP 12-30 Warning Parameter 12-31 Net Reference 12-32 Net Control
12-33 CIP Revision 12-34 CIP Product Code
12-35 EDS Parameter
12-37 COS Inhibit Timer
12-38 COS Filter
12-4* Modbus TCP 12-40 Status Parameter 12-41 Slave Message Count
12-42 Slave Exception Message Count
12-8* Other Ethernet Services 12-80 FTP Server 12-81 HTTP Server 12-82 SMTP Service 12-83 SNMP Agent 12-84 Address Conict Detection
12-85 ACD Last Conict
12-89 Transparent Socket Channel Port 12-9* Advanced Ethernet Services 12-90 Cable Diagnostic 12-91 MDI-X 12-92 IGMP Snooping
12-93 Cable Error Length
12-94 Broadcast Storm Protection
12-95 Broadcast Storm Filter
12-96 Port Cong
12-97 QoS Priority 12-98 Interface Counters
12-99 Media Counters
13-** Smart Logic 13-0* SLC Settings 13-00 SL Controller Mode
13-01 Start Event 13-02 Stop Event
13-03 Reset SLC
13-1* Comparators 13-10 Comparator Operand 13-11 Comparator Operator
13-12 Comparator Value
13-1* RS Flip Flops 13-15 RS-FF Operand S
13-16 RS-FF Operand R
13-2* Timers 13-20 SL Controller Timer 13-4* Logic Rules 13-40 Logic Rule Boolean 1 13-41 Logic Rule Operator 1
13-42 Logic Rule Boolean 2
13-43 Logic Rule Operator 2
13-44 Logic Rule Boolean 3
13-5* States 13-51 SL Controller Event 13-52 SL Controller Action 13-9* User Dened Alerts 13-90 Alert Trigger
13-91 Alert Action 13-92 Alert Text
13-9* User Dened Readouts
13-97 Alert Alarm Word 13-98 Alert Warning Word
13-99 Alert Status Word
14-** Special Functions 14-0* Inverter Switching 14-00 Switching Pattern 14-01 Switching Frequency 14-03 Overmodulation
14-04 Acoustic Noise Reduction
14-1* Mains Failure 14-10 Mains Failure 14-11 Mains Fault Voltage Level
14-12 Response to Mains Imbalance
14-16 Kin. Back-up Gain
14-2* Reset Functions 14-20 Reset Mode 14-21 Automatic Restart Time 14-22 Operation Mode
14-23 Typecode Setting
14-24 Trip Delay at Current Limit
14-25 Trip Delay at Torque Limit
14-26 Trip Delay at Inverter Fault 14-28 Production Settings
14-29 Service Code
14-3* Current Limit Ctrl.
14-30 Current Lim Ctrl, Proportional Gain
14-31 Current Lim Ctrl, Integration Time
14-32 Current Lim Ctrl, Filter Time
14-4* Energy Optimising 14-40 VT Level
14-41 AEO Minimum Magnetisation 14-42 Minimum AEO Frequency 14-43 Motor Cosphi
14-5* Environment 14-50 RFI Filter 14-51 DC-Link Compensation 14-52 Fan Control 14-53 Fan Monitor 14-55 Output Filter
14-56 Capacitance Output Filter
14-57 Inductance Output Filter
14-58 Voltage Gain Filter 14-59 Actual Number of Inverter Units
14-6* Auto Derate 14-60 Function at Over Temperature
14-61 Function at Inverter Overload
14-62 Inv. Overload Derate Current
14-8* Options 14-80 Option Supplied by External 24VDC
Appendix Operating Guide
MG21A502 Danfoss A/S © 09/2018 All rights reserved. 151
11 11
